Vmc CNC Milling Machine Center with 4 Axis for Sale
Basic Info.
Model NO.
VMC850
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
Movement Method
Linear Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.04~0.05(mm)
Performance Classification
High-End CNC Machine Tools
Certification
CE
Condition
New
Transport Package
Packing in Seaworthy Wooden Cases
Specification
Dimension(L*W*H): 3200*2800*3100mm
Trademark
DRC
Origin
China
Production Capacity
500
Product Description
VMC CNC milling machine center with 4 axis for sale| 3 Axis vertical metal Milling Machine Type | unit | VMC855(FANUC-Oi MF) |
| VMC Center Worktable | ||
| worktable(length×width ) | mm | 1000×500 |
| Maximum load of table | kg | 700 |
| T-slot(number of slot×slot×pitch) | mm | 5-18×80 |
| Triaxial itinerary | ||
| Travel forX/Y/Z axes | mm | 850/550/600 |
| Distance from spindle nose to table surface | mm | 100-650 |
| Distance spindle center to column guide surface | mm | 620 |
| Feed system | ||
| CNC system | | FANUC-Oi MF (1) α |
| Rapid shift of axes of X/Y/Z | | 36/36/16 |
| X/Y/Z axis motor | | βis12/βis12/βis22B |
| Spindle motor | | βiI12 |
| Automatic tool transform system (CNC milling without) | ||
| Standard tool quantity | | Disc type 24 |
| The larges diamter cutter knife/length | mm | Φ80 full tool/300 |
| Toolexchaing manner | | pneumatic |
| Average tool exchanging time | sec | Disc type2.5s |
| Precision | ||
| Positioning accuracy | mm | 0.008 |
| Accuracy of repeated positioning | mm | 0.005 |
| Spindle system | ||
| Spindle speed | r.p.m | 8000 |
| Spindle specifications | | BT40/190 |
| (Drive manner of spindle) | | Belt drive |
| (Motor power of spindle) | kW | 11/15 |
| Air pressure | ||
| Requirement for air compressing | kg/cm2 | ≥6 |
| Air pressure flux | L/min | 280 |
| Machine specifications | ||
| Integrated weight(kg) | kg | 6500 |
| Overall dimension (length×width×height) | mm | 2700×2300×3040 |
