Excavator Customized Multifunctional Loading Excavator Construction
| US$27,300.00-30,050.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
675H
Type
Wheel Excavator
Usage
GM Excavator
Bucket
Shovel
Transmission
Hydraulic Transmission
Drive Type
Internal Combustion Drive
Bucket Capacity
0.1~0.5m³
Size
Small-Scale
Certification
CE, ISO9001: 2000
Condition
New
Overall Weight
6500 Kg
Engine Model
Yc4fa65-T300
Power
50kw/2200rpm
Fuel Tank Capacity
92L
Walking Speed
32km/H
Rotation Speed
12r/Min
Bucket Digging Force
33.7kn
Hydraulic Pump Model
Ap2V071
Working Pressure
23MPa
Total Length During Transportation
5924
Minimum Ground Clearance
351
Tail Turning Radius
1842
Wheel Base
2400
Tire Type
235
Maximum Excavation Height
6528
Transport Package
Nude
Specification
5924*1910*2830
Trademark
HIGHRICH
Origin
China Shandong
HS Code
84295212
Production Capacity
1000/Year
Packaging & Delivery
Package Size
593.00cm * 191.00cm * 283.00cm
Package Gross Weight
6500.000kg
Product Description
Product ParametersMultifunctional wheeled excavator, time-saving and labor-saving, convenient and fast, with strong power, suitable for various scenarios. It is versatile and can be paired with different accessories. The luxurious cab is easy to operate and easy to get started. The powerful power system, coupled with the engine, can save resources and reduce consumption. The original hydraulic components have small power loss, fast action, high efficiency, strong reliability, and can extend the service life.
| Model:LG675H | Maximum flow rate:156.2+24+8L/min | J-Tire width:235 |
| Overall Weight:6500 kg | Working pressure:23MPa | K-Turntable width:1910 |
| Bucket capacity:0.28m³ | Hydraulic oil tank capacity:118L | L-Maximum excavation height:6528 |
| Engine model:YC4FA65-T300 | A-Total length during transportation:5924 | M-Maximum unloading height:4729 |
| Power:50KW/2200RPM | B-Full width during transportation:1910 | N-maximum excavation depth:3644 |
| Fuel tank capacity:92L | C-Full height of boom during transportation:2047 | O-Maximum vertical excavation depth:2750 |
| Walking speed:32KM/H | D-Full height during transportation:2830 | P-maximum excavation radius:6550 |
| Rotation speed:12r/min | E-Ground clearance of counterweight:1050 | R-Minimum turning radius:1940 |
| Gradeability:32° | F-Minimum ground clearance:351 | S-Maximum degree at minimum turning radius:4873/5100 |
| Bucket digging force:33.7kn | G-Tail turning radius:1842 | Stick length:1850 |
| Hydraulic pump model:AP2V071 | H-Wheelbase:2400 | boom length:3475 |
