Brass Water Meter Water Flow Meter Smart Cold Water Meter Jet pH Meter Ultrasonic Water Meter
| US$45.00-250.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
CX-GN
Install
Horizontal
Medium Temperature
Cold Water
Level Measurement
B
Counter Instructions
Digital and Analogue
Nominal Diameter
15-50mm
Application
Civil, Industrial
Principle
Speed of Water Meter
Medium Pressure
General Water Meter
Work Environment
Wet Water Meter
Stucture
Traditional
Product Name
Cold Water Meter
Accuracy
R=25/20/50
Size
DN50-DN300
Working Pressure
Pn16/25
Transport Package
Carton/Polywood Case /Wood Case
Specification
CE/SGS/ISO
Trademark
GN
Origin
Shanghai China
HS Code
9026100000
Production Capacity
1000PCS/Month
Packaging & Delivery
Package Size
50.00cm * 20.00cm * 20.00cm
Package Gross Weight
8.000kg
Product Description
Product Description| Product Name | High precision small flow intelligent cold water meter |
| Accuracy | R=25/20/50 |
| Size | DN50-DN300 |
| Working pressure | PN16/25 |
| Application | Measuring the volume of cold (hot) water passing through the pipeline.water meter is used for irrigation,municipality etc |
Features
·Removable element structure, easy installation and maintenance
·Dry-dial, Magnetic drive
·Large flow capacity, small pressure loss
·Resist water hummer and pollution
·Vacuum sealed register ensures the dial keep free from condensation and keep the reading clear in a long term service
·Selected high quality materials for steady and reliable characteristic
·Technical data conform to international standard ISO 4064/ISO9100
·With high accuracy
·Product accessories include connectors, filters, connection accessories, pipe accessories, Flange, filter
Optional Features
·Plastic register, copper register and full glass register
·Cold / Hot water
·Reed switch option
·Flange standard can be choose
·360 degree rotate can be choose
·Cast iron, Ductile iron, stainless steel,GG25,GGG50,SS304,SS316 body can be choose
·Provide pulse output
Working Condition
·Water temperature: 0.1ºC~50ºC (0.1ºC~90ºC for hot water meter)
·Water pressure: ≤1.0Mpa (1.6MPa on request)
Maximum Permissible Errors
·In the lower zone from qmin inclusive up to but excluding qt is ±5%
·In the upper zone from qt inclusive up to and including qs is ±2% (±3% for hot water meter)
