New Trend Mini Handheld Small Laser Welders Soldadora Laser Portatil with Air Cooling System

Product Description

New Trend Mini Handheld Small Laser Welders Soldadora Laser Portatil with Air Cooling System
Product Description
The air-cooled continuous laser cleaning machine can achieve efficient cleaning, non-destructive processing, energy saving and environmental protection.
Handheld laser welding is easy to learn, simple and fast to set up and provides consistent high-quality results across a wide range of materials and thicknesses. Anyone can learn to weld with professional results in 5-30mins. Compare this to years of training with a traditional Mig/Tig welder. With almost no flash, no need for heavy duty protective clothing to like traditional welding.
Product Parameters

Model	QYWL-FC800	QYWL-FC1200	QYWL-FC1500	QYWL-FC2000
Power (W)	800	1200	1500	2000
Rated power consumption (kW)	2.7	4	4.5	4.5
Power adjustment range (%)	10-100
Scan width (mm)	10-150/10-300
Focal length (mm)	400/800
Operating mode	Continuous wave
Central wavelength (nm)	1070~1090
Cooling method	Air Cooling
Fiber length (m)	10m			10m
Output method	Standard QBH
Auxiliary gas	Dry compressed air or inert gas after filtration.
Machine size (mm)	665*300*590
N.W (kg)	60
Power supply voltage (V)	220
Place environment	1.Ambient humidity 10 % ~ 85 % RH, no condensation. 2.There is no explosive and corrosive gas in the place where the equipment is installed. Environmental temperature 10 °C ~ 40 °C.
Working environment	Noise, ventilation, dust and other influencing factors.

Product Details
1. High-quality core components
MAX/Raycus/JPT/IPG laser, famous brand, customized options Omron / Chint famous electrical brand, safe, stable and reliable.
2. Portable welding head
Light weight with portable and flexible torch structure design, suitable for welding operation habits, stable and reliable.
Handheld and automatic machine dual-purpose, suitable for welding operations in high-strength and complex environments.

3. Universal wheel movable structure
Equipped with universal wheels, flexible movement, with good inlet and outlet air design of the shell ensures the overall heat dissipation and provides reliable welding guarantee for complex working conditions.
4. Open functional design
Fast power plug suitable for more working conditions;
Visual control panel, one-key operation with multi-language interface.

Product Application

Company Profile
SDQY Laser is a professional manufacturer of laser cleaning machines and laser welding machines, committed to providing customers with high-quality products and excellent services. As a company with its own R&D team, we continue to develop and innovate to provide customers with better solutions.
We are well aware of our customers' needs and requirements for our products, so we also provide free testing services so that customers can better understand our products and services. Customers are welcome to send us samples for testing, and we will provide test results and solutions as soon as possible.

FAQ
1.Are you a factory or a trading company?
We are the factory, located in Liaocheng, China.
Expecting your visit at anytime.

2.Is the price on your website is the closing price?
No, it is just for your reference, an exact quotation based on your requirement.
Please contact us for details.

3.May I inspect before delivery?
Sure, welcome to inspect before delivery.And if you can't inspect by yourself, our factory has a professional quality inspection team to inspect the goods before shipment to ensure quality.

4.How long is the delivery time of samples and bulk orders?
Sample lead time: About 5 working days. Order lead time: About 15 working days.
