3050 Multi-Function Hydraulic Radial Drilling Machine Safe Operation of Large Parts Processing

Product Description

Product Description
Rocker Arm Drill: A Comprehensive Introduction
The Radial Drilling Machine is an advanced piece of hole-processing equipment, expertly crafted for a variety of tasks such as drilling, reaming, tapping, and face trimming. Uniquely suited for both single and mass production, it excels in processing large parts with multiple holes, making it a staple in general machining workshops. Its exceptional features include:
Structural Features: The Rocker Arm boasts a remarkable ability to rotate and lift around the column, with the spindle box moving horizontally on the arm. This ingenious design provides unparalleled convenience, flexibility, and a wide application range, particularly when handling large and heavy workpieces.
Classification: Based on clamping structure, Radial Drilling Machines can be categorized into Hydraulic and Mechanical types. Further, depending on drilling size and mechanical principles, the Rocker Arm Drill is available in numerous models and specifications to address diverse processing needs.
Technical Parameters: Key technical parameters include maximum drilling diameter, spindle-to-column distance, spindle end face-to-working table distance, and spindle rotating speed. These critical parameters define the machine's machining capacity and efficiency.
Safety Performance: The Radial Drilling Machine is equipped with comprehensive safety features, including spindle cutting overload protection, spindle travel limit switch, and a lifting screw safety nut, all of which ensure safe operation.
Application: This versatile machine finds extensive use across various machining departments, undertaking tasks such as drilling, reaming, countersinking, tapping, and boring. It is indispensable in any machining and production environment.
Operation and Maintenance: Operating modes include manual and numerical control, with mechanical and hydraulic transmission options. Proper operation and diligent maintenance are key to optimizing machine performance and extending its service life.
In Summary: The Radial Drilling Machine is a multifunctional, efficient, and safe hole-processing marvel, adept at handling diverse metal parts processing. It stands as a vital asset in any modern machining workshop.
Product Parameters
Rocker Arm Drill: Performance Excellence
The Radial Drilling Machine represents a new era of multifunctional excellence, offering unparalleled performance and reliability. It features hydraulic primary variable speed mechanisms, reducing auxiliary time with spindle commands and brake operations. The diamond block clamping mechanism, hydraulically driven, ensures steadfast clamping throughout. With quenched parts like the rocker arm guide rail and cylindrical surfaces, it maintains precision and extends life. Its robust safety protection devices safeguard operations, making it a secure choice for any workshop.
Classification: Based on clamping structure, Radial Drilling Machines are divided into hydraulic and mechanical types. The hydraulic variant offers ease and dexterity, making it ideal for processing large parts with multiple holes, whether for single or mass production.

Product Name	Radial drill	Radial drill	Radial drill
Product model	3040*13/16	3032	Z3050*13/16
Maximum diameter of hole	casting40/Steel part35mm	casting32/Steel part27mm	casting50/Steel part45mm
Distance from spindle end face to table	430-1210mm	360-1050mm	360-1300mm
Distance from spindle center to column busbar	300-1100mm	260-1050mm	260-1050mm
Spindle travel	220mm	120mm	220mm
Main shaft hole cone	4Mohs	4Mohs	4Mohs
Spindle speed range	34.78.145..75130.560.260.430.920.380.760.1280rpm		34.78.145..75130.560.260.430.920.380.760.1280rpm
Spindle speed class speed	12	6	12
Spindle feed range	0.10-0.25rpm	0.10-0.25rpm	0.10-0.25rpm
Spindle feed series	3	3	3
Swing arm rotation Angle	Plus or minus 180 degrees	Plus or minus 180 degrees	Plus or minus 180 degrees
motor power	2.2kw	1.5kw	4kw
Machine weight	1400kg	9600kg	2400kg
Overall dimension	1500*705*2020mm	1350*705*1880mm	1950*810*2450mm
