Class B ISO4064 Single Jet Brass Body Dry Type Hot Water Meter

Product Description

Product Name: Vane Wheel Single-Jet Super Dry Dial Magnetic Type Cold (Hot) Water Meter
Specification:

Item	Standard
Operating condition	PN: 1.0/1.6 Mpa (10/16bar)
The water temperature	cold water up to 50ºC and hot water up to 90ºC
Standard	ISO 4064 Class B
Material	Brass
Size	DN15 - DN50
Pressure loss	ΔP63

Application:To totalize the total volume of water passing through the pipeline.
Features: Large measuring range, high flow accuracy; Long life of service; Reliable operation; Magnetic shield protection; Vacuum sealed register. Upon request, the meter can be equipped with pulse output device.
Error curve: From qt inclusive up to and including qs is ±2%; From qmin inclusive up to but excluding qt is ±5%.
Packing:Carton + pallet.
FAQ 1.Can i get free samples?
A: Yes,we can provide you the free sample, but you need to bear their own delivery costs.
2.Can I request to change the form of packaging and transportation?
A:Yes,We can change the form of the packaging and transportation according to your request, but you have to bear their own costs incurred during this period and the spreads.
3.Can i request to advance the shipment?
A: It should be depends on whether there is sufficient inventory in our warehouse.
4.Can i have my own Logo on the product?
A: Yes, you can send us your drawing and we can make your logo, but you have to bear
their own the cost.
5.Can you produce the products according to my own drawings?
A:Yes,we can produce the products according to your drawings that will be most satisfy you.
