Industrial-Grade Tire Shredder for Optimal Waste Management Solutions

Product Description

Single shaft shredder Main applicationThe single shaft shredder is applied to shred the tire and other scrap material(like furniture,TV case and so on) for convenient to further process of material. Equipment featuresAdopted the way of toothed blades rolling and shearing,optimized the stress situation blades and main shaft and reduce the consumption.Apply the cycloid reducer and hard tooth reducer,which has advantages of big bearing capacity,high efficiency,low noise and long lifespan and so on, Used wear resistant alloy blades which can be sharpened repeatedly so as to enlarge the blades lifespan.The blades are easily maintained and sharpened,and conveniently dismantled and installed.

Equipment model	TPD1200	TPD800
Motor power(Kw)	45-75	30-45
Moved blades Qty( Pcs)	88	64
Fixed blades Qty( Pcs)	3	2
Main shaft rotation speed (r/Min)	30-60	30-60
Shredder room length (mm)	1200	800
Screen hole size(mm)	Φ65-90	Φ65-90
Input size(mm)	Φ≤650	Φ≤500
Output size(mm)	40-60	40-60
Capacity(Kg/h)	1000	650
Size(L×W×Hmm)	2750×2000×2450	2550×1800×2450
Equipment weight(Kg)	8000	5500

About us
Dongguan Yuntong Environmental Protection Technology Co., Ltd. has been providing machinery design, manufacturing, installation, commissioning and maintenance, personnel training and other services based on the manufacturing and selling the scrap tire recycling and processing equipment since 1999. Providing personalized solutions according to customers' special requirements.
Our company have global advanced and professional technology in scrap tire recycling at normal temperature plant for fine rubber powder along with fully automatic industrial scrap rubber and plastic pyrolysis complete set of equipment , whoes various economic and technical indicators is in a leading position at the same industry . This technology has been widely promoted and applied which can comprehensively process the "black pollution" formed by scrap tire, and generate huge economic and social benefits.
After more than 20 years of continuous efforts, we have mastered dozens of proprietary patents (including 2 national invention patents and 9 new-type patents). And established a global marketing network, the equipment have successfully entered the international market, exported to Russia, Turkey, Cyprus, Algeria, Iran, India, Saudi Arabia,Uzbekistan, Australia,Malaysia, Indonesia, Vietnam, Canada, the United States, Trinidad and Tobago, Colombia, Peru, Argentina and many other countries more than 40 countries, as well as many domestic companies (Chongqing, Foshan, Hunan, Hong Kong, China, etc.),which are widely trusted and praised by our customers.
Focused, professional, technological innovation and keep moving, we are contributing our efforts to the circular economy and benefit humanity.
Services: 1,Tyre crushing equipment:Single shaft crusher,Twin shaft cruser,Tire super crusher,First granulator,Second granulator, Rubber powder machine
2,Tire slitting machine:Hydraulic tread strip cutter,Tire block cutter,Remote control sidewall strip cutter units,Hydraulic sidewall cutter,Sidewall cutter
3,screening installation:Line vibrating screen,Airflow classifier,Three layer vibrating screen
4,teel wire equipment:Tire bead cutter debeader,Bead wire rollers debeader,Deabeader
5,packing machine:Automatic weighing and packing machine
6,Accessories:Blades,filter screen
7,Rubber tile equipment units:Rubber mixer,Rubber tile vulcanizing equipment
8,Running track production units: Paver,Spraying machine, Line drawing machine
9,Automatic scrap rubber & plastic pyrolysis oil equipment
Our products can easily respond to a variety of car tires, bus tires, truck tires, agricultural tires, engineering tires , other rubber and plastic products.
Customers come to visit our factory
Our factory case Our certificate of honor
FAQ:
1. Q:Are you a factory or trading company? A:We are a professional Industrial and Trading Company,have more than 20 years production experiences. 2. Q:How does your factory do regarding quality control? A:"Quality is priority." We always attach great importance to quality controlling from the beginning to the end.
3. Q: What is your MOQ? A:Any quantity is acceptable for your order. And the price is negotiable for large quantity.
