HD3605y-11 High Precision Vmc, CNC Gantry Machining, CNC Horizontal Machining Lathe Machine

Product Description

-Robust box guideways crafted for intensive cutting tasks, ensuring precision and stability.
-Ingeniously designed 30° slanted one-piece bed structure enhancing overall rigidity and performance.
-Advanced stabilized unit structure effectively minimizes thermal displacement for consistent accuracy.
-Seamlessly integrated processing via synchronized control of Main/Sub spindle (SY Type) for optimal efficiency.
--Innovative multi-tasking capabilities with a wedge-type Y-axis BMT turret for expansive operational versatility.
Outstanding rapid traverse rate: 30m/min in the Z-axis for swift maneuverability.
-User-centric ergonomic design provides easy access to both chuck and tool for enhanced usability.

ITEM			UNIT	HD3605Y
CAPACITY	Swing Over the Bed		mm	940
	Swing Over the Carriage		mm	870
	Max.Turning Dia.		mm	300
	Max.Turning Length		mm	1280
	Bar Capacity	Main	mm	119
		Sub	mm	-
SPINDLE	Chuck Size	Main	inch	12"
		Sub	inch	-
	Spindle Bore	Main	mm	91
		Sub	mm	-
	Spindle Speed	Main	r/min	2,500
		Sub	r/min	-
	Motor(Max/Cont.)	Main	kw(HP)	18.5/15
		Sub	kw(HP)	-
	Torque(Max/Cont.)	Main	N·M	543/440
		Sub	N·M	-
	Spindle Type	Main	-	BELT
		Sub	-	-
	Spindle Nose		-	A2-11
			mm	-
	C-axis Indexing		deg	0.001
FEED	Travel	X/Y	mm	265/120{±60}
		Z/ZB	mm	1350
	Rapid Traverse Rate	X/Y	m/min(ipm)	24/10
		Z/ZB	m/min(ipm)	30
	Slide Type		-	BOX GUIDE
TURRET	No.of Tools		ea	12[24]
	Tool Size	O.D	mm	25[24Tool:20]
		I.D	mm	40
	Indexing Time		sec/step	0.2
	Y-Axis Type		-	WEDGE TYPE
LIVE TOOL	Milling Tool Speed		r/min	4,000
	Motor(Max/Cont.)		kw(HP)	4.5
	Torque(Max/Cont.)		N·M	76
	Collet Size		mm	∅20{ER32)
	Type		-	BMT65P
TAILSTOCK	Taper		-	MT#5
	Quill Dia.		mm	∅100
	Quill Travel		mm	120
	Travel		mm	1350
TANK CAPACITY	Coolant Tank		ℓ(gal)	225
	Lubricating Tank		ℓ(gal)	3
POWERSUPPLY	Electric Power Supply		kVA	35
	Thickness of Power Cable		mm²	Over 25
	Voltage		V/Hz	220/50
MACHINE	Floor Space(LxW)		mm	4,195x1,978
	Height		mm	1,857
	Weight		kg(lb)	7,400
CNC	Controller-		-	FANUC Oi Series

Detailed Photos
ALL-IN-ONE TYPE OF BED
Optimal Structural Analysis
Cutting-edge structural analysis applied to the machine design enhances the tool post size while lowering the machine's height, preserving dynamic bed rigidity even during demanding heavy-duty cutting operations.
Moreover, the HD-SY Series bed slope is meticulously angled at 30 degrees, ensuring exceptionally stable machining processes.
Integrated Coolant Tank
Ingeniously designed, the structure features the coolant tank at the bed front, boosting convenience, while chips can be effortlessly removed from the machine's right side.
Box Guideway
The sophisticated design of the HD-SY Series, utilizing box guideways across all axes, offers superior travel capabilities and effectively counters vibrations from heavy-duty cutting.
Sealed GIB Structure
The X-axis of the HD Series incorporates a sealed GIB structure to protect turcite from chip damage, ensuring longevity and reliability.
Rapid Traverse Rate (X/Y/Z/ZB)
HD 3605Y/SY delivers impressive speed: 24/10/30/24 m/min for rapid precision movements.
Travel (X/Y/Z/ZB)
HD 3605Y/SY offers substantial travel dimensions: 265/120/1350/1350 mm, accommodating a wide range of tasks.
Mill Turret
The BMT turret's innovative design secures tools with four bolts and a key on its mounting surface, ensuring unmatched rigidity and precision during operations.
Mill Tool Holder
Enhanced machining capabilities with the addition of a straight milling head tool holder for side machining and an angular milling head for I.D. operations.
BMT 65P (HD3605Y/SY)
Speed (rpm): 4000 r/min
Collet size: ø20 (ER32)
Indexing time: 0.2 sec/step
Suzhou Wugan Intelligent Equipment Co., Ltd. excels in crafting high-performance CNC lathes and turning centers, designed with cutting-edge international lathe technology. Fusing high rigidity, precision, productivity, and a sophisticated appearance, we deliver efficient, reliable cutting performance. To meet elevated customer demands, we offer a high-performance mill-turn combined model, capable of turning, milling, and drilling in one machine. This multifunctional approach not only amplifies product output capacity but also ensures our lathe series meets diverse processing needs with ease, satisfying a broad spectrum of customer requirements.
