Double Shaft Paddle Mixer Machine for Nitrogen Phosphorus Kalium Compound Fertilizer

Double Shaft Paddle Mixer Machine for Nitrogen Phosphorus Kalium Compound Fertilizer

US$4,000.00-200,000.00 1 set (MOQ)

Basic Info.

Model NO.
DPM
Application
Granules, Liquid, Powder
Application Area
Food
Certification
CE, ISO
Condition
New
Mixing Capacity
Customized
Mixing Drum Shape
Drum
Working
Convection Mixer
Steel Material
SUS304, SUS316L, Carbon Steel, Ti Alloy
OEM/ODM
Yes
Sample Test
Yes
Customized
Yes
Motor
ABB, Siemens, Mitsubishi, China Top Brand
Reducer
Flender, Sew, Nord, China Top Brand
Delivery Time
40 Days
Bearing
SKF, NSK, FAG, China Top Brand
Power Supply
Customized, 110~660V, 50/60Hz, Single/3-Phase
Mixer Type
Horizontal Weightlessness Mixer
Stirring Type
Forced
Layout Type
Horizontal
Operating Type
Cycle Operating
Warranty
18 Months
Transport Package
Standard Export Packing
Specification
100~30000L
Trademark
Higao Tech
Origin
China
HS Code
847982
Production Capacity
500 Sets/Year

Product Description

Product Description
1. Introduction:
Non-gravity double shaft paddle mixer is used to mix dry bulk solids like powder, granules, fiber, and mix bulk solids with liquids (moistening + granulating coating) or pastes.
Double shaft paddle mixer is designed and engineered for intensive mixing of two different wet and dry materials, or blending liquids and sludges with dry solids. These raw materials include sticky clays, sludges, filter cakes, silty soil, sandy soils and other abrasives.
2. Working Principle:
Double shaft paddle mixer consists of two parallel shafts with blending paddles fixed at a pre-determined angle. Blending paddles agitate materials, then make the movement of materials reach the critical rotation speed and there it can throw the materials to the highest point of the parabola. The critical point is called non-gravity point or zero-gravity point. So we sometimes people call this double shaft paddle mixer as Double shaft non-gravity mixer, or zero-gravity mixer, weightless mixer.
Relative rotation of the mixing paddles results in higher mixing efficiency.
Double shaft paddle mixer promotes a homogeneous mix for different particle sizes and density of the materials.
Detailed Photos
Product Parameters
(DPM Series) Non-Gravity Double Shaft Paddle Mixer (Twin Shaft Paddle Mixer) of HIGAO TECH
Model Total volume Loading volume Working capacity Spindle speed Motor Dimension(L×W×H) Weight
DPM-100 100L 60L 60kg 49rpm 3kw 1200×1100×750mm 300kg
DPM-200 200L 120L 120kg 41rpm 4kw 1250×1150×950mm 650kg
DPM-300 300L 180L 180kg 41rpm 5.5kw 1400×1250×1050mm 500kg
DPM-500 500L 300L 300kg 37rpm 7.5kw 1450×1500×950mm 800kg
DPM-1000 1000L 600L 600kg 33rpm 11kw 1800×1850×1350mm 1200kg
DPM-1500 1500L 900L 900kg 33rpm 15kw 1850×1950×1200mm 1500kg
DPM-2M3 2M3 1.2M3 1200kg 31rpm 15kw 2200×2400×1600mm 2200kg
DPM-3M3 3M3 1.8M3 1800kg 29rpm 22kw 2300×2300×1650mm 3500kg
DPM-4M3 4M3 2.4M3 2500kg 29rpm 22kw 2700×2400×1850mm 4500kg
DPM-5M3 5M3 3M3 3000kg 23rpm 30kw 2950×3100×2100mm 6000kg
DPM-6M3 6M3 3.6M3 3600kg 23rpm 37kw 3100×3200×2100mm 7000kg
DPM-8M3 88M3 4.8M3 4800kg 21rpm 45kw 3200×3300×2200mm 8000kg
DPM-10M3 10M3 6M3 6000kg 21rpm 55kw 3550×3350×2400mm 9500kg
DPM-12M3 12M3 7.2M3 7200kg 17rpm 75kw 4700×3600×2500mm 11000kg
DPM-15M3 15M3 9M3 9000kg 17rpm 90kw 5000×4000×2700mm 12000kg
Company Profile
Why choose us?
1. Real Steel Material: we have spectrometer for customer to check the material.
2. High machining accuracy: we use top brand CNC machining center, plasma and laser cuting machines, etc. to process components.
3. Professional work team: 10 engineers more than 20 year experience in R&D. Some production staff more than 30 year experience.
4. Standard production rules: we follow 5S industrial management standard to carry out our orders.
5. Strict quality control: we have QC to follow and check each working procedure as per industrial standard.
6. Customer approval: we have served more than 1000 customers in more than 50 countries.
7. Competitive price: German quality with Chinese price.
FAQ 1. How can I know your quality?
Our company is famuous in our industry. We have more than 20 years history. The best way to know the quality is comparison. You can come to our factory for on-the-spot investigation. You are welcome.
2. Can you supply sample test?
Of course our company can supply sample test before buying. And record the testing result and send to you by pictures or video.
3. What is your delivery time if I place order?
Usually 30~60 days. It depends on the machine itself, our actual order status.
4. Can you supply installation and commissioning service abroad when we received our equipment?
Yes, our company can send our engineers to your local workshop to guide installation and commissioning and training your operators.
5. How to operate and maintain the machine?
We will give you operation manual, drawing, circuit diagram spare parts list, etc after shipping.
6. What should I do if we can not solve the problems some times?
You just need to send email or make a call to us. We will reply within 12 hours and analyse the problems with you. Find the reason and find the way.
If we can not solve by communication after trying several ways, we can send our engineer to your place if you need.
7. What is your warranty period?
We supply one year warranty and life time after sales service for our euqipment.
