Character LCD Module 8X2 Yellow-Green Backlight 5V LCD Display Apply for Equipment

Product Description

Character LCD Module 8X2 Yellow-Green Backlight 5V LCD Display Apply for Equipment
Introduction
Character LCDs,can display letters (capital or non-capital), numbers, and punctuation. You can find this type of display in products such as vending machines, 3D printers, data loggers, etc.
General Description
Common Applications

Telecommunication Devices	Telephone,interphone,watch,tablet PC,radio,etc
Consumer Products	Camera,DVD player,toy, Cell Phone,game player,etc
Technical Equipment	Elevator controller,Industrial machine,etc
Office Automation	Printer,scanner,attendance machine,fax machine,etc
Home Appliances	Air-condition display,refrigerator,electric cooker,video doorbell,etc
Automobile	GPS,video player,speedometer,audio broadcast,etc
IT Products	Camera,handheld digital video,projector,media play,tablet PC,etc
Medical Equipment	Ultrasound machine,therapeutic equipment Blood pressure meter,etc

Advantages Easy ProgrammingMost of Focus LCDs' character lcds are equipped with a built-in driver. The driver contains a character table that is preloaded with letters, numbers, and punctuation in a particular language, allowing for easy programming. The character table eliminates the need to spend time programming each character. Focus LCDs' standard character LCDs all use an English font. However, upon request, an alternative driver with a different language can be used. Easy To Replace Discontinued Character LCDs One benefit of character LCDs is that they have a lower probability of being discontinued in comparison to newer, more complex display technologies. However, all displays are eventually discontinued at some point in time.
The good news is, it is relatively simple to develop an equivalent or close to equivalent replacement character LCD. Often times, Focus LCDs can produce direct cross overs for your discontinued character LCD and support it for many years.
If it is the driver that has gone EOL, you won't have trouble finding a close replacement. Most of Focus LCDs' character LCDs use driver ST7066 or equivalent. A comparison is made between 4 common character LCD built-in drivers in our LCD resource Character LCD Controller Compatibility ST7066.
It is important to note that while you won't have trouble finding a close replacement driver, considerations must be made in regard to your product's firmware. It is always advised to test samples before deciding on a replacement display.
Low Power Consumption
Character LCDs typically consume less power than displays such as TFTs. Focus LCDs' standard character LCDs come in 5V or 3.3V. The latter voltage is low enough to be powered by two double A batteries - perfect for low power or mobile devices.
LED backlights are a considerable source of power consumption on an LCD module. If power consumption is a major concern, and the environment of usage is well-lit, you should inquire about a character LCD that utilizes a reflective or transflective polarizer, eliminating the need for a backlight. This in turn significantly decreases power consumption.
You may be out of luck if your product requires a low power display and the environment of usage is not well-lit. In cases such as this, it is possible to implement pulse width modulation to dim or brighten the backlight as necessary. When the backlight is dimmed, it will draw less power.
Character LCD Variations As with all monochromatic LCDs, you are limited with your character LCD options in regard to colors. Positive mode character LCDs have dark pixels and a light background, while negative mode character LCDs have light pixels and a dark background.
When we refer to the background color, it is important to note that the background does not actually have a color. The background appears to be colored due to the color of the display's nematic fluid. Below are common liquid/mode color combinations:
FSTN Positive - Gray background, black text
FSTN Negative - Black background, light text
STN Positive - Gray/Yellow background, bluish-black text
STN Negative - Blue background, light text
Negative mode displays require a backlight to be read. The color of the light text on a negative mode LCD is dictated by the color of the LED backlight. For example, a red LED backlight will shine through the light text and make it appear red.
Focus LCDs' standard character variations range from 8×1 to 40×4 characters and have several different models for each variation.
ConclusionReaper offers a wide range of standard Character LCD modules for customers' application. Our LCD character displays are available from 8x2, 12x2, 16x1, 16x2, 16x4, 20x2, 20x4, 24x2 through to 40x4 formats with 5x8 dot matrix characters. The LCD panel technologies include TN, STN, FSTN, FFSTN types and also with polarizer positive mode and negative mode options. There are different LED backlights are available in various colors including yellow/green, white, red, blue, green, amber, and RGB LEDs as well as no backlight option.
To meet the demands of customer applications, these character LCD displays are available with viewing angles of 6:00, 12:00, 3:00, and 9:00 o'clock. Reaper offers various IC options of character fonts including English/Japanese, western European, eastern European, Scandinavian European, Cyrillic (Russian), and Hebrew/Arabic. These LCD character module and LCM Modules can be used on industrial and consumer's applications including entrance guard's equipment, telegram, medical device, car and home audio, white goods, game machine, toys and etc. Packaging & Shipping & Delivery
Packaging Details:
All the products are packed in right way to keep it safe.
For small sizes of products we use tray + carton,
For bigger sizes we use foam slot + carton.
we also design packages according to customers' requirements
Shipping Details:
For small quantity orders: we ship by UPS Air-Express, or DHL/FEDEX/TNT/ EMS Express service, it is safe and fast.
For large quantity orders: we ship by buyer's cargo agent in China,
we can also ship by air or sea transportation by our cargo agent.
Delivery Details:
Ready-made Sample: within 1 week
Custom Sample: 1~2 weeks
Mass production: 3-4 weeks
Quality Policy:
All materials we purchase for making any orders are high quality and RoHS compliant, and Control quality with ISO 9001:2008 management system.
Advance inspection instrument and equipment to ensure 100% inspection for each and every piece before shipment
