Junlin Open Rubber Mixing Mill (XK-230) , Mixing Mill

Product Description

mode	xk-230
ltem
working diameter of rollers(mm)	230
working length of rollers(mm)	600
linear speed of front rollers(m/min)	10.94
speed ratio of front and rear roller	1:1.19
capacity per.batch (kg)	6-10
motor power (kw)	15
overall size l*w*h(mm)	2800*1200*1120
weight(kg)	2300
notes	nylon bush use grease for lubricating,copper bush and bearing use grease or oil

Open mixing mill
The mill is mainly for rubber warming,plasticating,mixing and sheeting.
Specification:160-810
Product Description
Rubber Open Type Mill
Product Description:
junlin Rubber Mill Machine is used for mixing and kneading raw rubber, synthetic rubber, thermoplastics or E.V.A. with chemicals into even materials. The even materials can be fed to calender, hot presses or other processingmachiner3t for making rubber or plastic products. It adopts dual output reducer, the front and behind roller can be driven separately with rolling bearing structure, the roller can adopts hollow center groove roller or drilling hole smooth roller against difference using scope as mixing, refining or press pieces etc.
This machine can be installed stock blender according to customer s request to decrease the labor strength, also equipped with safe device.

mode	xk-160	xk-230	xk-250	xk-360	xk-400	xk-450	xk-560	xk-610	xk-660	xk-710	xk-810
ltem
working diameter of rollers(mm)working diameter of rollers(mm)	160	230	250	360	400	450	560/510	610	660	710	810
working length of rollers(mm)	320	600	620	900	1000	1200	1530/1830	2000	2130	2200	2540
linear speed of front rollers(m/min)	8.03	10.94	14.1	16.25	18.65	24.5	27.87	30	28.6	31.9	32
speed ratio of front and rear roller	1:1.35	1:1.19	1:1.17	1:1.25	1:1.27	1:1.27	1:1.2	1:1.29	1:1.24	1:1.15	1:1.27
capacity per.batch (kg)	1-2	6-10	10-15	20-25	18-35	25-30	50-100	90-120	130-165	150-200	180-250
motor power (kw)	7.5	15	18.5	30	37	55	90/110	160	185/250	285	2*250
overall size l*w*h(mm)	1380*860*1320	2800*1200*1120	3800*1500*1500	3850*1650*1750	4250*1850*1870	5200*1800*2000	6500*2300*2000	7500*2500*2640	7600*3400*2500	8246*3556*2270	9736*5160*2070
weight(kg)	1000	2300	3000	6500	7000	10000	20000	28000	47000	51000	74500
notes	nylon bush use grease for lubricating,copper bush and bearing use grease or oil

XK-230Product Description
1. The xk-230 rubber mixing mill with CE and ISO9001 features an alloy chilled cast iron roller with a highly durable and wear-resistant surface that undergoes mirror processing. The roller also has inner hollow spray type design for uniform temperature distribution.
2. The roller is equipped with ball bearings and a grease lubrication structure.
3. The roller adopts worm wheel and worm drive devices, allowing optional installation of motorized nip adjustment for easy operation.
4. This machine has a whole base structure, making it convenient to install.
Problems of customer concern:
About machine performance quality
1.Q:How old is Junlin factory?
A:The company has a history of 15 years since its inception in 2009
2.Q:What is the delivery time?
A:The delivery time of the machine is 15-60 days
3.Q:Which countries can I send to?
A:It can be delivered anywhere in the world
4.Q:How about the quality of the product?
A:The machine is guaranteed for up to one year. During the problem company to send accessories
