CE Approved Universal Cylindrical Grinder Machine (M1420)
| US$5,000.00-10,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
M1420
Abrasives
Grinding Wheel
Controlling Mode
Artificial
Automatic Grade
Manual
Cylindrical Grinder Type
Universal Cylindrical Grinder
Precision
Precision
Certification
CE, RoHS, ISO 9001
Condition
New
Grinding Diameter
2-80mm
center height
115mm
Working piece weight
10kgs
motor
2.34kw
Tail Taper
MT3
Transport Package
Plywood Case
Specification
1500Kgs
Trademark
HOTON
Origin
Shandong, China
HS Code
8460190000
Production Capacity
10 PCS/Month
Product Description
CYLINDRICAL GRINDING MACHINE FEATURES:
Universal cylindrical grinder machine
High precision
Good performance
ISO certificate
SPECIFICATIONS:
| MODEL | MW1420 |
| grinding diameter | dia2-80mm |
| center grinding length | 300mm |
| center height | 115mm |
| max work piece weight | 10kg |
| worktable speed | 0.1-4m/min |
| wheel peripheral velocity | 35m/sec |
| max travel of table | 340mm |
| swivel range of table | -3-+7degree |
| external wheel size | 180-250mm*25*75mm |
| internal wheel spindle speed | 1600r/min |
| tail center | MT3 |
| machine size | 1360*1240*1000 |
| weight | 1500kg |
| motor power | 2.34kw |
| working accuracy | |
| roundness | 1.5/2.5(0/d,i/d) |
| surface roughness | RA0.25/0.63(o/d,i/d) |
| uniformity of diameter in longitudinal section | 5/8UM(O/D,I/D) |
| Contact Us: |
| Andy Wang TENGZHOU HOTON MACHINERY CO.,LTD Tel:0086 632 5633796 MP:0086 13506328892 hotonmachinery.en.made-in-china.com |
| Company Profile: |
| Tengzhou Hoton Machinery Co.,LTD was established in 2006, and is the professional machine manufacturer in China. There are 480 workers, of whom 60 are engineers. It has an area of 46,000 square meter, general assets 30,000,000. It has a store of 350 equipments and the good ability of products design & manufacturing. It has export quality permit from 2007, and has export right given by the State Foreign Economic Trade Committee in 2008. |
| The leading products: "Hoton" series of CNC machines, Lathes, Milling machines, Drilling machines,Grinding machines, Saws, Sheet metal machines, Metal forming machines, and other machine accessories.Some products have national patent.It has fourteen series, over eighty models by itself. It has the ability of making 100,000 sets every year. All the products are designed perfectly and has high quality high performance and low price, and the excellent quality guarantee system. The products have past ISO9001 and CE certification since 2009. The products have been export to five continents, over forty countries and areas. It resulted to the attraction of client abroad and home, the quickly promotion of products sale. |
| Tengzhou Hoton Machinery Co.,Ltd. is willing to make common progress and developments with all the customers. Quality first,Constantly perfecting skills. |
