Durable and Compact Remote Cloud Control LPG Gas Generator for Mobile Power Solutions in Remote Locations
| US$1,000.00-13,800.00 | 1 units (MOQ) |
Basic Info.
Model NO.
SC38WNG
Output Type
AC Three Phase
Gas Source
Gas
Certification
CE, TLC, ISO, CCC
Power
50-200kW
Standard
Standard
Product Type
Diesel Generator Set
Rated Frequency(Hz)
50/60Hz
Power Section
50Hz 25-670kVA 60Hz 25-720kVA
Alternator
Famous Brand
Cyl
L4 / L6 / L12
Controller
Deep Sea, Comap, Smartgen
Engine
Brand New Diesel Engine
Optional
ATS, Oil Heater, Engine Heater, Separator
Brushless Alternator
AC 220V, 380V, 400V, 4. 15V, 440V, 480V
Absorbers
Anti Vibration Suspension
Main Line Circuit Breaker
ATS
Weight
900-7500kg
Starting System
24V Electric System
Protection
IP23
Foot
Solid Damping Foot
Transport Package
Wooden Packing
Specification
2500*1000*1500
Trademark
Cameo
Origin
Chongqing
HS Code
85021100
Production Capacity
500000pieces/Year
Packaging & Delivery
Package Size
2620.00cm * 1120.00cm * 1600.00cm
Package Gross Weight
1280.000kg
Product Description
Type : Gas typePower section : 50HZ 25-670KVA 60HZ 25-720KVA
Alternator : Baudouin
Controller : DSE8610MKII, HGM9530, AGC150
Product description: Senci Gas generator set With Famous brand engine and brushless alternator and Deepsea controller.1. Silent type unit Soundproof and weatherproof canopy, which is made by 1.5- 2mm cold steel.
2. The best powder coating with chemical surface treatment ensure corrosion resistance and coating quality.
3. 5mm mute cotton and good exhaust system. Noise level ≤75dBA at 7 meters
4. Forklift hole and lugs are mounted on the base frame.
5. Emergency stop button mounted on canopy to faciliate emergency operations.
6. Control panel viewing window allows users to monitor the control panel.
7. Lubricant and coolant drain are installed for convenient replacement.Our gas generator sets are highly compatible to work with the urban gas network or with fuel tanks. Thanks to the standardisation of its production, we can offer efficient gas generators at the best price on the market.
Product Parameters
| Gas Generator Three Phase (50HZ) | |||||||
| Soundproof Type | ESP | PRP | Engine Model | Cyl | Displacement | TypeDimention | Weight |
| kva | kva | L | mm | Kg | |||
| SC38WNG | 30 | 25 | WP4D40E200NG | 4 | 4.5 | 2500*1000*1500 | 1250 |
| SC75WNG | 60 | 50 | WP4D77E300NG | 4 | 4.5 | 2600*1000*1500 | 1300 |
| SC125WNG | 100 | 80 | WP6D132E300NG | 6 | 6.75 | 3500*1200*1800 | 1950 |
| SC188WNG | 150 | 120 | WP1CEI200E300NG | 6 | 9.726 | 4100*1500*2000 | 2900 |
| SC313WNG | 250 | 205 | WP13D317E300NG | 6 | 12.54 | 4200* 1800*2000 | 4300 |
| SC500WNG | 400 | 320 | 6M33D450E310NG | 6 | 19.6 | 4800*2200*2200 | 6350 |
| SC625WNG | 500 | / | 12M26D6O5E300NG | 12 | 31.8 | 5500*2200*2200 | 7750 |
| SC1000WNG | 800 | 670 | 12M33D900E310NG | 12 | 39.2 | 5800*2250*2450 | 8000 |
| Gas Diesel Generator Three Phase (60HZ) | |||||||
| Soundproof Type | ESP | PRP | Engine Model | Cyl | Displacement | TypeDimention | Weight |
| kva | kva | L | mm | Kg | |||
| SC38WNG | 30 | 25 | WP4D44E201NG | 4 | 4.5 | 2500*1000*1500 | 1250 |
| SC75WNG | 60 | 50 | WP4D77E301NG | 4 | 4.5 | 2600*1000*1500 | 1300 |
| SC125WNG | 100 | 80 | WP6D132E301NG | 6 | 6.75 | 3500*1200*1800 | 1950 |
| SC225WNG | 180 | 145 | WP10D238E301NG | 6 | 9.726 | 4100*1500*2000 | 2900 |
| SC313WNG | 250 | 205 | WP13D317E301NG | 6 | 12.54 | 4200*1800*2000 | 4300 |
| SC500WNG | 400 | 330 | 6M33D480E311NG | 6 | 19.6 | 4800*2200*2200 | 6350 |
| SC688WNG | 550 | / | 12M26D660E301NG | 12 | 31.8 | 5500*2200*2200 | 7800 |
| SC1063WNG | 850 | 720 | 12M33D960E311NG | 12 | 39.2 | 5800*2250*2450 | 8050 |
1. Environmentally friendly, greatly reducing particulate emissions.
2. Economical and reliable, perfect for applications where continuous use is required, which produces great savings compared to diesel.
3. Environmentally friendly, greatly reducing particulate emissions. Economical and reliable, perfect for applications where continuous use is required, which produces great savings compared to diesel. Highly compatible and applicable: they can be installed in remote locations with large capacity tanks.
4. Silent: these sets emit less decibels of acoustic power than at the same powers in diesel.
5. High efficiency in cogeneration.
