Bestsellers Cow Dung Dryer Chicken Manure Drying Equipment for Animal Manure, Sludge, Food Waste

Product Description

Product Description
Cow dung dryer is a new type of rotary dryer professionally designed and developed by Dingli Company according to market demand. This new dryer is suitable for cow dung, chicken manure, poultry manure, sawdust, wood flour, wood chips, wood shavings, Barley straw, oat straw, wheat straw, rye straw, rice straw, broom corn straw, peanut vine, corn straw and other materials. According to the different characteristics of each raw material, different production capacity, application requirements, cost control, degree of automation, optimization of drying process technology, on-site working conditions, etc., we can design the drying process.
Dingli Company recommended product: this cow dung rotary drum dryer unit capacity is larger, high efficient, saving energy, covers area is less, it can saving energy more than 50% than the ordinary dryer, it can maximize saving energy and drying costs.

Product Advantages
1) The poultry Manure Drying Granulation Equipment Line can realize the automatic and intelligent control, the operation parameters can be automatically controlled, the dryer is always in the best condition to running, it can be ensure uniform drying out of the raw material moisture is stability.
2) The inside of Manure rotary dryer has the unique flights to hits and tumbling the materials. In order to maximize efficiency of heat transfer between the material and drying air. The output of equipment increase more than 50% and the fuel energy consumption decrease more than 30%.
3) This machine uses four-wheel drive assembly. The driving is more stable and reliable.
4) The spatial footprint of general rotary drum dryer less footprint about 40%. The civil investment reduced about 40%. The equipment cost decrease about 20%.
5) The internal structure of the dryer use various efficient flight patterns. It can efficiency adjust the feed and heat distribution. The high heat efficiency, waste are exhausted temperature is lower than 50 .
6) Adopts frequency motor control the material flow, heat supply, and drum rotate speed. It can easily adjust according to the needs of the outlet material moisture content and equipment output.
7) This type dryer use the modular dust collector purifying and heat recycling assembly. It is safe and protect environmental.
8) The Manure dryer is several options for new type energy-saving hot air furnace, high efficiency and energy saving, heating can be control, simple operation, energy consumption decrease about 30%, power consumption reduce 20%, and lower operation costs.


Process & Principle
Material Flow : 75-85% moisture content of the material fed into the special dehydration machine, the water removed to about 65% through the screw conveyor into the mixing drum dryer to downstream drying. Flights pick up material, carry it over, and shower it through the air stream as the drum rotates, promoting maximize efficiency of heat transfer between the material and drying air. The rapid evaporation of water vaporization, to achieve the effect of drying materials in the hot air under the rapid flow of the drum. The rotary drum dryer gives material a chance to dry before it hits the next flights, in order to prevent buildup near the wet material discharge. Drum cleaning device is installed inside of the drum to prevent the material sticking issue.
Air Stream Flow :The air through the air blower increase pressure into the hot air furnace to heating, when the temperature reached to 600-850, the hot air will be into dryer to drying wet material and evaporation water by induce draft fan. Through three-layer heat transfer, the air temperature reduces to 55-65 and then discharge from dryer. The dust and moisture are purified trough the cyclone dust collector and wet dust collector.


Product Application
Chicken Manure Drying Granulation Equipment Line is suitable for chicken manure, cow dung, feces organic fertilizer, sludge, bean dregs, starch residue, sauce residue, sprayed corn kernels, cassava residue, beer distiller's grains, lees, straw, pasture and other 50-85% moisture content of material Drying. All of our drying process technology according to the characteristics of each biomass material, the size of production, the application requirements, the cost control, the degree of automation, the site conditions etc.


Specifications
Other Related Technical Parameters We can help optimize the drying process according to the property of different materials, production scale, application requirements, cost control, automation level and site condition.

Model(DLJG)	1208	1408	1610	2010	2010/3	2210/3	2510/3	2512/3
Input Capacity(t/h)	1.82	2.18	3.15	3.81	4.76	5.51	6.33	7.6
Output Capacity(t/h)	1.07	1.28	1.85	2.24	2.8	3.24	3.72	4.47
Vaporization(t/h)	0.75	0.9	1.3	1.57	1.96	2.27	2.61	3.13
Early Moisture(%)	50±5%
Final Moisture(%)	15%(adjustable)
Drying Temperature(°C)	350±30
Total Power(KW)	32	40	55	95	95	100	125	145
Total Weight(T)	15	17	21.5	26.5	26.5	28.5	37	41
Plant Area(M)	5*15	5*15	6*16	8*18	8*20	8*20	10*20	10*22
Except above models, we also can supply special model according to your requirements.

Our Service
Below is Dingli Group Packaging & Shipping: Your device will be packed well in container and suit for long ocean shipping.
Below is Dingli Group Service Items: Pre-sale
1. According to your needs, select right model for you.
2. According to your special requirements, design customized solution and manufacture customized products for you.
3. Welcome your visit.
Sale
1. Sign contract, pay deposit, we arrange production.
2. Product acceptance.
3. Help you formulate construction scheme.
After-sale
1. Assign engineer service for you on-site freely.
2. Install and adjust device, train how to operate.
3. After installation, leaving 1-2 technical staff to help you on-site production, until achieve customer satisfaction.
Company Information
Dingli Group Advantage: 1. Over 200 employees, 98% professional technical personnel;
2. Factory size over 15,000 square meters;
3. 480 Inventions & Patents
4. Exported over 80 countries,300 global partners;
5. Rank 3rd in China Drying Industry;
6. Customize Drying Production Line.
Below are Dingli Dryer Factory & Sales Team & Production Workshop Pictures:
Below are Dingli Group Honors & Certificates & Patents:
Buyer & Project Case
Below are Dingli Customers Visiting: Dingli Dryer Production Line has exported to over 80 countries with 300 foreign partners, such as Germany, Britain, United States, Italy, Israel, Chile, Thailand, Russia, Vietnam, India, Cambodia, Indonesia, Malaysia, Thailand etc.
Below are Installation Sites of Our Customers: After reach deals, Dingli Engineer will fly to your address, install and adjust machine for you freely.
Also train you operation skills, until you are satisfied.
