800X2000 Automatic Horizontal Surface Grinder Machine

Product Description

Surface Grinding Machine Introducing the Surface Grinding Machine from Jiangsu Zhihe Intelligent Equipment Co., Ltd. This machine features a tetrafluoroethylene soft belt on the worktable and saddle flat guideway for smooth operation. The combined guideway structure integrates the saddle, column, and roller for enhanced stability.
The vertical and head cross movements are powered by ball screws, with the grinding head cross movement driven by an oil motor. Additionally, the oil pool is equipped with an oil cooling device to maintain optimal performance.

SPECIFICATION		M7180
Size of worktable ( L × W × H )		mm	1250*800*600	1600*800*600	2000 × 800*600	3000*800*600
Max . Longitudinal movement of worktable		mm	1350	1700	2100	3100
Max. Distance from the spindle centerline to the worktable surface		mm	825	825	825	825
Max. Cross movement of grinding head		mm	863	863	863	863
Vertical movement of the grinding head by hand wheel	Per graduation	mm	0.005	0.005	0.005	0.005
	Per revolution	mm	0.5	0.5	0.5	0.5
Rapid lifting motor	Power	KW	0.75	0.75	0.75	0.75
	Speed	r/min	910	910	910	910
Abrasive wheel dim ( D × W × d )		mm	450*63*203	450*63*203	450*63*203	450*63*203
Speed of grindwheel		r/min	1440	1440	1440	1400
Total power of motor		Kw	21	21	23.6	27.6
Power of spindle motor		KW	11	11	11	15
Power of o il pump motor		KW	7	7	8	11
Processing accuracy		mm/mm	300/0.008	300/0.008	300/0.008	300/0.008
Surface roughness			Ra:0.63	Ra:0.63	Ra:0.63	Ra:0.63
N/G weight		kg	11150/12150	11500/12500	12000/13000	13000/14000
Packing size(LXWXH		mm	6270*2540*2825	6620*2540*2825	7020*2540*2825	8220*2540*2825

Welcome to Jiangsu Zhihe Intelligent Equipment Co., Ltd. 1. How can I choose the most suitable machines?
A: Please provide your specifications, and we will help you select the best model. Alternatively, you can choose the exact model or send us product drawings for our recommendation.
2. What are the main products of your company?
A: We specialize in various machines including surface grinding machines, CNC surface grinders, CNC milling machines, vertical machining centers, drilling machines, gantry milling machines, and CNC gantry grinding machines.
3. Where is our factory located? How can I visit there?
A: Our factory is situated at NO 370 Changjiang North Road, Nantong, Jiangsu, China. Kindly inform us in advance if you wish to visit, and we will make necessary arrangements.
4. What are your trade terms?
A: FOB, CFR, and CIF are all acceptable.
5. What are the Payment Terms?
A: We accept T/T with a 30% initial payment upon ordering and a 70% balance payment before shipment. Irrevocable LC at sight is also an option.
6. What is the MOQ?
A: The MOQ is 1 set, with only some low-cost machines requiring more than 1 set.
We would like to know:
1. What is your Industrial Voltage?
2. It is recommended to provide the size and material of your workpiece for evaluation. Sending workpiece drawings would be even better for us to recommend the most suitable model.
3. If you require CIF Price, please specify the port of destination.
