HAWKER BATTERY AX12-45 12V45Ah AGV
Detailed description
Mobile machines, including all kinds of mobile intelligent robots and AGV vehicles,the power of its own source is the battery. In order to ensure that the mobile machinery can be continuous, stable, safe and reliable work, reasonable configuration of power supply, choose to use high efficiency, and low cost battery, it is very important.
Hawker Power Group Limited is the world's most advanced power supply manufacturer. To meet the requirements of emerging applications, with its advanced manufacturing equipment and processes, the latest patented technology and materials, designed for mobile mechanical power supply adsorption (AGM) AX series maintenance-free lead-acid sealed batteries. The series of batteries in strict compliance with the international standard battery production, not only to strengthen the deep cycle discharge and fast charge capacity, but also improve the use of security and reliability, no damage to equipment and the environment, no pollution.
Follow the standard
● Product design in line with international standards IEC 60896 / 21-22
● In accordance with the Eurobat guidelines issued in 1999, this series of products belong to the "long life" category
● Complies with Telcordia SR-4228
● UL certification (UL standard 1989)
● According to the US "DOT Regulation 49" and the ICAO ICAO and IATA "Packaging Directive 806", it was approved as a non-dangerous goods suitable for land, sea and air transport
● certified by ISO 9001: 2000 and ISO 14001: 2004 certified Hawker factory production

Specifications and technical specifications

Types parameter		AGM (Adsorption) AX Series
		AX12-18	AX12-26	AX12-33	AX12-45	AX12-60	AX12-75	AX12-100	AX12-120	AX12-150	AX12-180	AX12-200
Single voltage		12V
Rated Capacity （25℃）		18AH	26AH	33AH	45Ah	60Ah	75Ah	100Ah	120AH	150AH	180AH	200AH
Internal resistance(mΩ)		10.0	8.0	9.0	7.0	6.5	6.0	5.0	4.5	4.0	4.0	3.8
Single size	Length (mm)	181	166	195	198	260	260	308	408	485	530	522
	width (mm)	77	175	130	166	170	170	170	177	170	210	240
	height (mm)	168	125	180	170	185	235	215	225	240	215	225
weight (kg)		5.9	9.0	10.2	14.6	20.2	23.5	30	36.5	47.0	53.0	63.0
Short circuit current (A)		900	900	1150	1250	1450	1750	2300	2420	2950	3350	3750
Maximum discharge Current(A)		180	260	330	450	600	765	1025	1200	1510	1850	2100
Maximum charge current(A)		3.6	5.2	6.6	9	12	15	20	24	30	36	40
Charging voltage：Temperature: 25 ℃, float: 13.62V; fast charge: 14.2V proper temperature：-10℃～40℃ Recommended temperature: 20 ℃ ~ 25 ℃ Number of deep cycle discharges：More than 1200 times 50% DOD; more than 800 times 80% DOD
Terminal		M5	M5	M6	M6	M6	M6	M8	M8	M8	M8

Introduction
Hawker HuaDa EV series of power battery, is the international advanced level of lithium iron phosphate (LiFePO4) power battery system. With high energy density, long cycle life, excellent charge and discharge performance, good temperature performance, is a new generation of high security and high reliability of the green power supply.
This series of batteries is the use of the latest development of the battery management system (BMS), specifically for mobile mechanical equipment, online charging and wireless charging and design and production of power batteries, with advanced battery self-management, communication, alarm and short-term fast charge Complete function.
Product Features
● Excellent charge and discharge overvoltage and undervoltage protection
● provide analog output AO, SOC analog output 0 ~ 5V, user-friendly power monitoring
Note: SOC can only be used as a reference, can not be used as a decision.
● Provides a highly efficient passive equalization system
● Charge / discharge are all with short circuit insurance
● Panel LED power, system status display
● Rich interface, through the digital IO and 485 interface to achieve information exchange
● professional industrial design and material selection, sustainable work in the harsh industrial environment
● support high-power charge and discharge, to meet the needs of a variety of different industrial conditions
● wide temperature working environment conditions, -20 degrees -60 degrees
● small size
Dimensions specifications

Types	Battery size Long*wide*high（mm）	Charge continuous current	Discharge continuous current
EV24-40	315*237*165mm	80A	20A
EV24-60	315*240*215mm 320*237*188mm 460*220*150mm	120A	30A
EV24-80	355*330*215mm	160A	40A
EV24-100	355*330*215mm	200A	50A
EV24-120	400*275*245mm	180A	60A
EV24-200	550*210*425mm	200A	100A
EV48-30	345*238*200mm	60A	30A
EV48-60	590*240*240mm	120A	30A
EV48-80	585*345*230mm	160A	40A
EV48-100	585*345*230mm	200A	50A
EV48-160	605*435*255mm	160A	80A
EV48-200	615*650*250mm	160A	100A
EV48-250	605*290*480mm	200A	125A

Performance specifications

project	Features
Overvoltage protection	3.7V (single string)
Undervoltage protection	2.8V (single string)
Charging parameters	Maximum 2C lasts for 10 minutes, 1C continues
Discharge parameters	Up to 1C continuous
Charge and discharge port form	Charge and discharge
fuse	Have
RS-485 communication	Have
Analog output AO	Have
Configurable DO output	Have
Power LED display	Have
Master switch	Have
Operating temperature	-20℃~60℃
Storage temperature	-20℃~70℃
Working humidity	Relative humidity of 10% to 80%, no condensation
cooling system	Passive natural cooling
Charger requirements	Lithium iron phosphate battery charger
Battery shell color	Toyota White (customizable)
