Features for Agriculture Machine Harvester 4lzt-4.0zd Rice Combine Harvester
Basic Info.
Model NO.
4LZT-4.0ZD
Application
Cotton, Rice, Corn, Fruit, Wheat, Soybean, Tubers, Straw
Power Source
Electric
Harvest method
Vibration fall
Drive Type
Vee belt
Transmission
Soft Shaft
Portable Harvester Type
Backpack Type
Certification
QS, ISO9001:2008, CE
Color
Green
Condition
New
Application Field
Agriculture, Livestock, Aquaculture, Forestry
Warranty
1 Year Warranty
Transport Package
Cartons
Trademark
Zoomlion
Origin
China
HS Code
8429521200
Production Capacity
500000
Product Description
Features for Agriculture Machine Harvester 4LZT-4.0ZD Rice Combine HarvesterUpgraded and optimized travelling system brings better trafficability in paddy field and higher efficiency.
Chasis with higher ground clearance with min.clearance of 315mm, better trafficability in paddy field and higher efficiency
Upgraded and optimized header conveying system, strong ability of handling crops, systematically solve the problem of troubled feeding in longitudinal axis flow model
New driveline system with reinforced and more reliable material
2SB belt is used as the conveying belt in conveying sink, with higher conveying efficiency and longer service life;imported bearings are used in key parts with better reliability
Screen widened to 1080mm, with 15% larger screening area, ensure perfect cleaning and very low impurity.
Specification Specifications for Agriculture Machine Harvester 4LZT-4.0ZD Rice Combine Harvester
| Model | Unit | 4LZT-4.0ZD |
| Dimension (L×W×H) | mm | 5270*2500*2960mm |
| Threshing drum(length*φ) | / | 2000mm×φ620 |
| Cutting width | m | 2 |
| Cleaning sieve | | 1.76 |
| Feeding capacity | kg/s | 4 |
| Efficiency | acre/h | 1.2~1.5 |
| Engine power | hp | 88 |
| Rubber track | mm | 500mm width*90mm pitch*53 section high stripe track |
| Fuel tank | L | 160 |
| Grain tank capacity | m3 | 1.4 |
| Transmission | / | Mechanical+HST(Hyro-Static Transmission) |
| Min. ground clearance | mm | 325 |
| Unloading Height | 4m 270° rotary | |
| Weight | kg | 3260 |
| Harvesting Crops | / | Rice, Wheat, Corn, Soybeans, rapes |
