Original Enerpac Thin Hydraulic Cylinder Rcs-1002

Product Description

Product DescriptionRSM, RCS-Series, Low Height Hydraulic Cylinders RSM-Series, Flat-Jac® Cylinders
Compact hydraulic cylinder wtih a flat design for use where most other cylinders will not fitSingle-acting, spring returnRSM-750, 1000 and 1500 cylinders have handles for easy carryingMounting holes permit easy fixturingBaked enamel finish for increased corrosion resistanceCR-400 coupler and dust cap included on all models1)Hard chrome plated high quality steel plungersGrooved plunger ends require no saddle. RCS-Series, Low Height Cylinders
Lightweight, low profile cylinder design for use in confined spacesSingle-acting, spring returnBaked enamel finish for increased corrosion resistancePlunger wiper reduces contamination, extending cylinder lifeCR-400 coupler and dust cap included on all modelsGrooved plunger end with threaded holes for mounting tilt saddlesIntegral handle on RCS-1002 for easy carryingPlated steel plungers. Cylinder
Capacity Stroke Cylinder
Effective Area Oil
Capacity Collapsed
Height Extended
Height Outside
Diameter Weight

Model Number
	ton (kN)	mm	cm2	cm3	mm	mm	mm	kg
5 (45)	6	RSM-501)	6,5	4	32	38	58 x 41	1
10 (101)	12	RSM-100	14,5	18	43	54	82 x 55	1,4
20 (201)	11	RSM-200	28,7	32	51	62	101 x 76	3,1
30 (295)	13	RSM-300	42,1	55	58	71	117 x 95	4,5
45 (435)	16	RSM-500	62,1	99	66	82	140 x 114	6,8
75 (718)	16	RSM-750	102,6	164	79	95	165 x 139	11,3
90 (887)	16	RSM-1000	126,7	203	85	101	178 x 153	14,5
150 (1368)	16	RSM-1500	198,1	317	100	116	215 x 190	26,3
10 (101)	38	RCS-101*	14,5	55	88	126	69	2,7
20 (201)	45	RCS-201*	28,7	129	98	143	92	5,0
30 (295)	62	RCS-302*	42,1	261	117	179	101	6,8
45 (435)	60	RCS-502*	62,1	373	122	182	124	10,0
90 (887)	57	RCS-1002*	126,7	722	141	198	165	20,7
