Prophyridium Purpureum Algae Culture Photobioreactor Pipeline Reactor System

Product Description

Product Description Photobioreactor Prophyridium purpureum algae culture photobioreactor pipeline reactor system The algae PBR pipline bioreactor ,can make depend on customer 's requirements . from 5L-50000L.
For Chlorella, spirulina, Dunaliella salina,Schizosporophyta, Prophyridium Purpureum all type algae culture .
For pigment , protein extraction project , for human. After then ,can use tubular centrifuge/disc stack centrifuge for algae solid harvest .
The pipeline photobioreactor can be customized:
1. Different pipeline photobioreactor structures can be designed according to the different algae cultivation of customers, and the capacity can be increased or decreased at will, which is suitable for laboratory or large-scale industrial use. 2. Material selection can be plexiglass (acrylic, PMMA) or boric acid glass
3. Provide suitable circulating pumps in industrial large-scale algae culture pipeline reactors (selection of large flow,
continuous work, no shearing force on algae cells)
4. Design ventilation and gas control devices
5. Good and reliable anti-leakage and detachable solutions
6. Provide various indicator detection and recording functions, and provide other output connection methods such as lab view or serial port.
The technical date :

PRODUCT NAME	200L PBR	500L PBR	1000L PBR	2000L PBR	5000L PBR
Model	PBR-200L	PBR-500L	PBR-1000L	PBR-2000L	PBR-5000L
Tubelar capacity	150L	400L	500L	1000L	2000L
Tank capacity	50L	100L	500L	1000L	3000L
Total Production capacity	200L	500L	1000L	2000L	5000L
Glass tube diameter	Φ65/Φ110	Φ65/Φ110	Φ65/Φ110	Φ65/Φ110	Φ65/Φ110
Glass tube material	High borosilicate	High borosilicate	High borosilicate	High borosilicate	High borosilicate
Tank material	PMMA	PMMA	PE	PE	PE
Water pump power	2.2kW	2.2kW	2.2kW	2.2kW	3kW
LED spectrum	white	white	white	white	white
LED power	200W	400W	400W	800W	1.6KW
PH online monitoring	0-14	0-14	0-14	0-14	0-14
Temperature Online monitoring	0-100ºC	0-100ºC	0-100ºC	0-100ºC	0-100ºC
Material of Tubelar section	PVC	PVC	PVC	PVC	PVC
Total power	3kW	3kW	4kW	4kW	5kW

The driving mode of the pipeline photobioreactor can be combined with multiple operation driving modes:
1. Reduce dissolved oxygen and increase carbon dioxide 2. Reduce energy consumption, solar panels can drive the system to run 3.Reduce cell adhesion to the wall and clean the inner wall of the pipeline 4. Choose a reasonable drive mode according to cell characteristics
A)Parallel pipeline circling pipe structure photobioreactor
B)Vertical structure pipeline photobioreactor C) Pond structure
D) Algae Harvest Centrifuge
