Nanyang Mj329/2SD-Q Wood Cutting Band Sawmill Log Carriage China Factory 1200mm Max Sawing Diameter Vertical Wood Band Saw Machine Automatic Carriage

Product Description

NANYANG MJ329/2SD-Q Wood Cutting Band Sawmill Log Carriage China Factory 1200mm Max Sawing Diameter Vertical Wood Band Saw Machine Automatic Carriage
Product Description
Automatic Carriage For Band Saw
The Band Saw Automatic Carriage is one of the main equipment of wood processing machinery. It uses a band saw blade to cut wood in a straight line. Its main structural components are: machine base, fuselage, upper and lower saw wheels, saw card, and saw blade tensioner.
This product has a reasonable structure, reliable performance, smooth operation, and simple operation. It is especially suitable for collective operations and individual processing. It is an ideal woodworking machine for the wood processing industry and wood product manufacturing industry.
Product Parameters
Technical Parameters

Item	MJ329/2SD2-Q	MJ329/2SD3-Q	MJ329/2SD4-Q
Max. sawing diameter	1200mm	1200mm	1200mm
Max. sawing length	2000mm	3000mm	4000mm
Max.Forward speed	39m/min	39m/min	39m/min
Max.BackWard speed	82m/min	82m/min	82m/min
Footage speed	37.8mm/s	37.8mm/s	37.8mm/s
Max. stroke of the air cylinder	800 mm	800 mm	800 mm
Inner Dia. of the air cylinder	φ100mm	φ100mm	φ100mm
Total motor power	4.5kW	4.5kW	5.2kW
Track length	9000mm	9000mm	12000mm
Dimensions	2800×1700×1850mm	3300×1700×1850mm	4600×1700×1850mm
Weight	1800kgs	2500kgs	2800kgs

It consists of shafts, wheels, and supports. It needs to run on two parallel rails during movement and is equipped with a ruler for measuring when processing wood. Some are equipped with lasers for more accurate measurements.
When woodworking is processing wood, manpower can be used to carry the wood, but when the wood is relatively heavy, it can be used instead of manpower, which has a strong load-bearing capacity.
Product Function
1. Automatic forward and backward; Pneumatic hook
2. PLC control system; Touch screen display
3. Servo motor control
4. Automatic concede
Automation Control Panel
Easy to operate
The console is usually well-designed with a clear layout of operating buttons and control panels, allowing the operator to easily master the use of the equipment.
Easy to adjust
The adjustment buttons and levers on the console are relatively simple and intuitive to operate, and can easily adjust the cutting angle, cutting depth, and other parameters.
Good view
The design of the console allows the operator to observe the cutting process more clearly, which is beneficial for improving work accuracy and safety.
Efficient and high-speed
It can quickly complete wood-cutting operations and improve production efficiency.
High cutting accuracy
The equipment has high cutting accuracy and can ensure the flatness and accuracy of wood cutting.
Safe and reliable
The equipment has safety protection measures, such as overload protection, automatic shutdown when power is off, etc. to ensure the safety of operators.
Compact structure
The equipment occupies a small area and is suitable for wood processing operations in limited spaces.
Easy to operate
The equipment is equipped with an automated control system and is easy to operate. The operator only needs to set parameters to complete the cutting operation.
Energy saving and environmental protection
Compared with traditional circular saws, it is more energy-saving, reduces energy consumption, and meets environmental protection requirements.
