Double Plate Type Continuous Screen Changer for Plastic Extruder

Product Description

Double plate type continuous screen changer for plastic extruder
Benifits of this double plate type continuous screen changer for plastic extruder
1) leak-free operation
2) no shut down the working machine
3) easy operation
4) increased the filtration area
5)continuous operation increase the output
Working principle
As polymer enters the screen changer the melt stream is divided equally and distributed through two rheologically optimized breaker plates. This method of filtration provides increased screen area as compared to single breaker plate screen changer designs and maintains a streamlined polymer flow path. Polymer merges back to a single melt stream as it exits the screen changer.
Application
. Sheet
. Coating
. Pipe
. Compounding
. Wire and cable
. Tubing
. Textiles(fibers and nonwovens)
. EVA, hot melt adhesive and PSA
. Pelletizing(strands and underwater)
. Recycling of most polymers
Cast film
. Corrosive and degradable materials
. Textiles (fibers and nonwovens)
Types

Type	ScreenD&A		overall dimension (mm)				Heating power (KW))	Output (kg/h)
	Dia(mm)	Filtration area(cm2)	L	W	H	L1
GM-DSP-80	80	50x2	200	170	240	820	2.4/3.2	110-300
GM-DSP-100	100	78x2	220	185	280	930	3.5/4.7	180-500
GM-DSP-120	120	113x2	260	205	320	1010	5.0/7.2	350-800
GM-DSP-150	150	176x2	300	235	360	1140	8.2/11.1	450-1200
GM-DSP-180	180	254x2	320	245	360	1200	9.4/12.7	500-1500
GM-DSP-200	200	314x2	360	280	420	1300	10.2/13.8	800-2500
GM-DSP-250	250	490x2	450	300	430	1520	13/17.5	1400-3700
Remark:The output rates depend on the individual extrusion process parameters.

Optional choice
Adpters support stands down stream equipments: suach as Gmach melt gear pump filter mesh/screen vacuum cleaning furnace Pelletizing system
Tips for customers
How to choose a most suitable type of screen changer for your extrusion line ?
After the equipment supplier making a size recommendation and then you should perform your own analysis to confirm appropriate sizing. That way, you will have the advantage of independent analyses and, best of all, there is no additional cost.
Learn the difference between price and cost. Be sure to take into consideration all of the variables and look at all the factors to determine the real cost of ownership for the screen changer. Some of the hidden variables to consider may be:
Product quality.
Maintenance, time and cost of parts.
Process downtime and cost.
Life expectancy for the equipment and amortized cost of ownership.
Cost and availability of filtration media.
Pressure loss and effect on line output and product quality.
Operator safety.
Required operator intervention and labor cost.
If all of these and other factors are taken into consideration, you can choose the most suitable solution, and then you can expect a much better return on investment.
