Phosphor Copper Strip C5191 C5210 C5100

Product Description

We are the leading manufacturer and export of Phosphor Bronze Strips with ASTM and JIS standard, we can supply Phosphor Bronze Strips as follow: Specificationsphosphor Copper strip:
1) Thickness 0.05mm - 4.0mm
2) Alloy brand: C5191, C5210, C5102. C5212 etc
3) Width: 8mm-610mm. Chemical Composition: C5191: Cu + Tin + P >99.5% Tin: 4.5-5.5% P: 0.03%-0.35% C5191: Cu + Tin + P >99.7% Fe < 0.1% Pb < 0.05% Zn < 0.2% Tin: 7.0-9.0% P: 0.03%-0.35%
Temper: 1/2H, 3/4H, H, EH, SH Packaging & Delivery

Packaging Detail:	Standard export seaworthy package of phosphor bronze strip (or by the customer's request)
Delivery Detail:	30 days after received the advanced payment.

Features of phosphor Copper strip Good elongation; endurance, and corrosion-resistance; being electroplated well

Type No.	Alloy No.	Chemical Composition						Features&Application
		Cu+Sn+P	Fe	Pb	Zn	Sn	P
PB	C5102	99.5>	_	_	_	4.5-5.5	0.03-0.35	Features:good elongation:Endurance,and corrosion-resistance.
	C5191	99.5>	_	_	_	5.5-7.0	0.03-0.35	Application:Electronics,Springs,switches,lead frames,connectors,diaphragms,bellows,fuse clips and so on used in electronic machine
	C5212	99.5>	_	_	_	7.0-9.0	0.03-0.35
PBS	C5210	99.7>	0.10<	0.05<	0.20<	7.0-9.0	0.03-0.35	Features:good elongation:Endurance,and corrosion-resistance.
								Application:Switches,relays,and connectors used in machines of electronics,communication information,and measurement.

Process of phosphor Copper strip
Raw Material → Melting → Horizontal Continuous Casting → Annealing → Milling → Rough Rolling → Side Trimming → Intermediate Rolling → Continuous Annealing & Picking → Intermediate & Finish Rolling → Degreasing → Strips Applications of phosphor bronze strip

C5191	Electronics, springs, switches, lead frames, connectors, diaphragms, bellows, fuse clips, and so on used in electronic machine.
C5210	Switches, relays, and connectors used in machines of electronics, communication, and measurement.

Should any specification are you interesting in, pls let me know, we are happy give you excellent price and more better service.
Looking forward to hear from you in order to establish mutually profitable business relations
