Universal Vertical Drilling Machine with CE Certification (Z5032C/1)
Basic Info.
Model NO.
Z5032C/1
Structure
Vertical Drilling Machine
Layout
Vertical
Controlling Mode
Artificial
Hole Diameter
<50mm
Automatic Grade
Semiautomatic
Precision
Normal Precision
Certification
GS, CE, RoHS, ISO 9001
Condition
New
Max. drilling dia.
32
Spindle travel
130
Distance between spindle nose and table
700
Distance between spindle nose and stand
1125
Distance from spindle axis to column
290
Spindle box travel
250
Table size
730*210
Transport Package
Plywood Case with Steel Base
Specification
1000*950*1850
Trademark
luzhong
Origin
China
Production Capacity
50000 Pieces/Year
Packaging & Delivery
Package Size
1000.00cm * 950.00cm * 1850.00cm
Package Gross Weight
520.000kg
Product Description
Universal Vertical Drilling Machine with CE Certification (Z5032C/1)Product Description
Product Parameters
Product main technical Specifications:
| Specifications | Z5032C/1 | Z5040C/1 | Z5045C/1 |
| Max. Drilling dia. | 32mm | 40mm | 45mm |
| Spindle taper | M.T.3 or R8 | M.T.4 | M.T.4 |
| Spindle travel | 130mm | 130mm | 130mm |
| Step of speed | 6 | 6 | 6 |
| Range of spindle speed 50Hz | 80-1250 r.p.m | 80-1250 r.p.m | 80-1250 r.p.m |
| 60Hz | 95-1500 r.p.m | 95-1500 r.p.m | 95-1500 r.p.m |
| Step of spindle auto-feeding | 6 | 6 | 6 |
| Range of spindle auto-feeding amount | 0.06-0.30mm/r | 0.06-0.30mm/r | 0.06-0.30mm/r |
| Min.distance from spindle axis to column | 290mm | 290mm | 290mm |
| Max.distance from spindle nose to worktable | 700mm | 700mm | 700mm |
| Max.distance from spindle nose to stand table | 1125mm | 1125mm | 1125mm |
| Max.travel of headstock | 250mm | 250mm | 250mm |
| Swivel angle of headstock(horizontal) | 360° | 360° | 360° |
| Max.travel of worktable bracket | 600mm | 600mm | 600mm |
| Table Size | 730×210mm | 730×210mm | 730×210mm |
| Size of stand worktable of avaliability | 417×416mm | 417×416mm | 417×416mm |
| Forward and afterward travel of worktable | 205mm | 205mm | 205mm |
| Left anf right travle of worktable | 500mm | 500mm | 500mm |
| Vertical travel of worktable | 570mm | 570mm | 570mm |
| Motor Power | 0.75kw | 1.1kw | 1.5kw |
| speed of motor | 1400rpm | 1400rpm | 1400rpm |
| Coolant pump power | 0.04kw | 0.04kw | 0.04kw |
| Net weight/Gross weight | 437/500kg | 442/502kg | 443/505kg |
| Packing size | 1850x750x1000mm | 1850x750x1000mm | 1850x750x1000mm |
Detailed Photos
Company Profile
FAQ
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
