Box Hammer Crusher Crusher Manufacturers for Sale Used in Marble Limestone Crushing

Box Hammer Crusher Crusher Manufacturers for Sale Used in Marble Limestone Crushing

US$14,286.00 1 Piece (MOQ)

Basic Info.

Model NO.
Optional
Cutter Material
Cermet
Drive
Electromagnetic
Object
Coal, Metal, Plastic
Type
Gyratory Crusher
Advantage
High Efficiency Low Energy
Spare Parts Supply
Anytime
Factory Visit
Welcomed Warmly
Quality
Advanced Technology
Color
Customer Requirement
Transport Package
Standard Container
Specification
Refer to parameters
Trademark
Anshun
Origin
Henan, China
HS Code
84742090
Production Capacity
40000 Sets/Year

Packaging & Delivery

Package Size
2100.00cm * 1200.00cm * 1700.00cm
Package Gross Weight
3000.000kg

Product Description

Product Introduction
This machine is used to crush medium-hard brittle materials, such as limestone, coal and other materials. The maximum compressive strength of the crushed materials does not exceed 150kg/cm. It is mainly used in highways, railway stones, cement, mining, coal preparation, power generation, chemical industry and building materials. It is particularly suitable for stone factories with an output of less than 300 cubic meters per hour. It has a compact structure, reasonable process, small investment and high economic benefits.

Working Principle
The rotor disc is driven by the motor to drive the hammer to do high-speed circular motion. When the material enters the crushing chamber, the large pieces of material are piled on the middle shoulder bar set in the machine. After being crushed, the material with a particle size larger than the required size is hit along the tangent direction of the hammer head to the impact plate for further crushing along with the new material, so that the coarse and medium crushing are completed in one step. Finally, the material that meets the requirements is discharged after being integrated through the sieve plate.
Performance characteristics
1. Large feed size, large crushing ratio, uniform discharge;
2. High yield rate, granular products account for about 85%, fully meeting the use requirements;
3. High output and stable performance;
4. Coarse and medium crushing in one step, simplified process flow;
5. High wear-resistant materials are used for hammers, sieves and impact plates, which have a longer service life;
6. Small matching power, low energy consumption, simple maintenance, and few wearing parts.
Specifications and Performance Parameters
Model 700×1000 900×1200 1000×1000 1000×1200 1400×1400 1600×1600 1800×1800
Rotor Diameter(mm) 700 900 1000 1200 1400 1600 1800
Rotor Length(mm) 1000 1200 1000 1000 1400 1600 1800
Production(t/h) 50-80 70-100 90-120 90-120 190-210 250-300 300-400
Input Size(mm) ≤500 ≤800 ≤800 ≤900 ≤1000 ≤1000 ≤1200
For Stone Various types of stone(compressive strength under 300mpa)
Power(kW) 45-55 75-90 75-90 90-110 132-160 160-210 210-280

Applicable materials
medium and fine crushing of hard and medium hard rocks such as quartz, river pebbles, calcite, dolomite, granite, basalt, iron ore, limestone, diabase, bluestone, etc.
