Best Selling High-Quality for Wire and Cable Protection 1/2inch 3/4 Inch 1inch PVC Electrical Conduit Pipe

Product Description

Best Selling Gray White Orange Blue PVC Pipe for Water Supply Drainage Irrigation Conduit
Product Description
Product Parameters

Nominal pressure	0.63MPa	0.8MPa	1.0MPa	1.25MPa	1.6MPa
Standard dimension ratio	SDR26	SDR21	SDR17	SDR13.6	SDR11
Nominal outside diameter (mm)	Wall thickness	Wall thickness	Wall thickness	Wall thickness	Wall thickness
20	-	-	-	-	-
25	-	-	-	-	2.0
32	-	-	-	2.0	2.4
40	-	-	2.0	2.4	3.0
50	-	2.0	2.4	3.0	3.7
63	2.0	2.5	3.0	3.8	4.7
75	2.3	2.9	3.6	4.5	5.6
90	2.8	3.5	4.3	5.4	6.7
110	2.7	3.4	4.2	5.3	6.6
125	3.1	3.9	4.8	6.0	7.4
140	3.5	4.3	5.4	6.7	8.3
160	4.0	4.9	6.2	7.7	9.5
180	4.4	5.5	6.9	8.6	10.7
200	4.9	6.2	7.7	9.6	11.9
225	5.5	6.9	8.6	10.8	13.4
250	6.2	7.7	9.6	11.9	14.8
280	6.9	8.6	10.7	13.4	16.6
315	7.7	9.7	12.1	15.0	18.7
355	8.7	10.9	13.6	16.9	21.1
400	9.8	12.3	15.3	19.1	23.7
450	11.0	13.8	17.2	21.5	26.7
500	12.3	15.3	19.1	23.9	29.7
560	13.7	17.2	21.4	26.7	-
630	15.4	19.3	24.1	30	-
710	17.4	21.8	27.2	-	-
800	19.6	24.5	30.6	-	-

*We can customize the products according to your requirements.
Application
Pvc pipe is widely used in industrial and civil building, including indoor and out door drainage,sewage pipe project, agricultural irrigation system, chemical drainage, sewage, it also suitable for ventilation pipe and drainage pipeline, etc.
Certifications
Packaging & Shipping
Company Profile
Shandong Guangdu Pipe Co.,Ltd is professional manufacturer of plastic pipes and fittings with more than 15 years exporting experience. Our company has 30 production lines and covers an area of 20,000 square meters.
Our company's main products are: HDPE,PVC,PP-R,MPP and other series, widely used in construction engineering, municipal engineering, agricultural irrigation and drainage, gas transportation, home improvement, power cable sheathing and other fields. There are nearly 3,000 kinds of pipes and fittings and valve products of different varieties and specifications.
Customer Visit
With 15 years of exporting experience, we have received friends from all over the world. The friends we met at the exhibition and those who visited our factory all spoke highly of our products. We are business partners, but also friends in life. We hope to have more friends to join our big family.
FAQQ1: What is the Raw material ?Re: 100% virgin raw material.
Q2: May I get one sample before placing order?
Re: Yes, Sample are available. Samples are for free and you just need to bear the freight.
Q3: Which payment is available for your company?
Re: T/T, L/C . You can choose the one which is convenient for you.Q4: What is your MOQ?Re: As customers' requests. Q5: why choose us?Re: We are a professional manufacturer with competitive price, good quality and fast delivery time.Q6: Can you Offer OEM service?Re: Yes, we can.Q7: What is the shipping port?Re: Qingdao port or Customer designated port.
