Super Viewing TIG/MIG Auto Darkening Automatic Welding Helmet / Grinding Mask (WH9801)

Product Description

Super Viewing Welding Helmet (WH9801)
a. This product is of completely new design, with shell material high-and-low temperature resistant, corrosion resistant, flame retardant, soft, light tight, intensity high and durable
b. Clear vision on the work piece both prior and welding, which means improved quality and higher efficiency
c. Overall-process protection against ultraviolet and infrared ratiation. WH8000 is equipped with lithium battery and solar cells that extends the life of the battery.
d. The product is in full conformity with related ANSI, CE, CSA, AS/NZS safety
e. Special feature: equipped with 4 arc sensors, more sensitive and professional. 100*97mm big viewing size makes welding work much easier and comportable

WH9000 SERIERS

Welding Mask Model: WH9000
Auto Darkening Welding Filter Option:
WH801, WH602, WH603, WH604
Color Available: blue/black/silver/red/other pattern
Brand: Welhel/ Neutral package/ OEM





Parameter of Filter model: WH801
Light state: DIN4 Dark state: DIN5-9/9-13 Switching time: <1/25,000S at Room Temperature Cartridge Size: 133 x 114x 9mm (5.25" x 4.5" x 0.35") Viewing area: 100x93 mm (3.94" x 3.66") Sensitivity: Stepless Adjustment Delay time: Stepless Adjustment 0.15S ~0.80S Shade Adjustment: Outside & Stepless Sensors: 4 Optical class: 1/1/1/2 TIG Capability: >2A
Grinding Power Supply: Replaceable Li-Mn & Solar Combination UV & IR protection: Up to shade 16
Certification: CE ANSI ROHS Warranty (years): 2 Weight: 495G (1.09 Pound) Material of helmet: NYLON
Patented Design
Patented Registration No.:ZL201330403199.9
Other Auto Darkening Welding Filter Options
for WH9000 series:

AUTO DARKENING LENS SPECIFICATIONS
		EXPERT
MODEL		WH800 Series	WH600 Series			WH900 Series
		WH801	WH602	WH603	WH604	WH913	WH912
Cartridge Size (mm)		133*114	133*114			110 x 90
Lens Thickness (mm)		9				8
Viewing Window Size (mm)		100*93	100*67
Weight (g)		170	160	150	179	108
Light State		DIN4
Dark State		DIN5-9/9-13				DIN9-13
Switching time (ms)		0.04
Delay time Adjustment	Inside & Stepless (0.15~0.80s)	√				√
	Inside & Switch (Fast/Slow 0.25s/0.70s)
	Outside & Stepless				√
Sensitivity Adjustment	Inside & Stepless	√				√
	Inside & Switch (Low/High)
	Outside & Stepless				√
Shade Adjustment	Outside & Stepless	√	√		√	√	√
	Inside & Stepless			√
Sensors		4			4	2
Grinding	Outside	√			√	√
	Inside			√
Power Supply	Solar power & Lithium Battery combination
	Solar power & replaceable battery	√
	Solar power & rechargeable battery
TIG Capability		≥2A
Warranty (years)		2
	Optical class	1/1/1/2
Certification	CE EN379	√
	ANSI Z87.1	√
	GS					√
