100W Pd Charger, USB-C Wall Charger

100W Pd Charger, USB-C Wall Charger

US$13.00
2,000-9,999 Pieces
US$12.00
10,000-19,999 Pieces
US$11.00
20,000+ Pieces

Basic Info.

Model NO.
PD 100W
Power Source
Electric
Quick Charging Function
With Quick Charging Function
Charger Cable Length
<4 Feet
Over-Current Protection
With Over-Current Protection
Display
Without Display
Color
Black
Socket Type
For USA/Canada
Customized
Customized
AC Input Plug
Us
Charging Interface
USB-C
Charging Power
100W Max. (5A@20V)
Input Voltage Range
100-240VAC
Input Frequency Range
50/60Hz
Output Voltage
20V@5A;15V@3A;9V@3A;5V@3A
Over Volatage Protection
Yes
Over Current & Short Ciruit Protection
Yes
Ambient Temperature
-5ºC ~40ºC @ Full Load
En61000-4-2 Electronstatic Discharge
6kv Contact Discharge, 8kv Air Discharge
Environment Compliance
Meet 2011/65/EU Directive
Transport Package
PE Bag + Waterproof Bag + Carton
Specification
63mm(L)*61.50mm(W)* 30mm(H)
Trademark
MASS POWER OR ODM
Origin
China
Production Capacity
100000PCS/Month

Product Description

Detailed Photos
Product Description DESCRIPTION : WALL MOUNT
1, INPUT VOLTAGE RANGE
MIN. NORMAL MAX.
90VAC 100-240VAC 264VAC
INPUT FREQUENCY RANGE
MIN. MORMAL MAX.
47Hz 50/60Hz 63Hz
2, OUTPUT CHARACTERISTIC
STATIC LOAD
Output Voltage Total Regulation Load Range
5V 4.75-5.25V 3A
9V 8.55-9.45V 3A
15V 14.25-15.75V 3A
20V 19.00-21.00V 5A
3, OUTLINE DRAWING Notes: 1). Physical size: 63.00±1.0mm(L)*61.50±1.0mm(W)* 30.00±1.0mm(H) 2). Unit: mm 3). Material: PC945, UL94V-0 4). Color: BLACK 5). AC Input Plug: US 4, NAMEPLATE
Notes: Unit: mm 1.Laser The QR code's number have nine digits,For Example:123456789 Number 1 to 2, means laser mechine No.:per code 1~9, A~Z(no include I,O) Number 3, means Year, 1~9,A~Z(no include I,O), for example "9" for 2019,"A" for 2020 Number 4, means Month,1~9 for Jan to Sep, "A" for Oct, "B" for Nov, "C" for Dec Number 5, means Date,1~9,A~X(no include I,O),for example "A5G" for 2020/05/16 Number 6 to 9, means serial number: 1~9, A~Z(no include I,O) QR code size:7mm*7mm,type:QR Code Digit Size:0.9mm(H)(±0.5mm) The distance from QR code size to the digit size:0.5-1mm 5,ENVIRONMENTAL COMPLIANCE RoHS Meet 2011/65/EU directive and its amendment (EU) 2015/863
PACKAGING Meet 94/62/EC directive
REACH Meet (EC) No.1907/2006 directive
WEEE (Waste Electrical and Electronic Equipment) Meet 2012/19/EU directive
