High Quality Automatic Loading and Unloading Mlk 650q Grinding Machine
| US$15,000.00 | 1 units (MOQ) |
Basic Info.
Model NO.
MLK 650Q
Control
Semi-Automatic
Application
Metal
Power Source
Electric
Layout
Vertical
Product Scope of Application
"Less Than 200 ( Diagonal) Greater Than 12 (Thickn
"Autotransmeration Speed of The Workpiec
"100r/Min "
"Mainframe Weight "
5500(Kg)
"G Grinding Wheel Specifications "
"650*250*50 "
Transport Package
1800 (Length) X 1200 (Width) X 2300 (High)
Specification
1800 (length) x 1200 (width) x 2300 (high)
Trademark
fuhe
Origin
Shandong
Product Description
| Machine parameters MKL-650T1 MKL-650T11 MKL-650Q | |||||||
| Product application range | Less than 150(diagonal) | Less than 120(diagonal) | Less than 200(diagonal) greater than 12(thickness) | ||||
| Workpiece material | Steel, cast iron, ceramics, copper, aluminum, cemented carbide, magnetic materials (grinding wheel optional according to the material) | ||||||
| Spacing between two grinding wheels | 80 | ||||||
| Spindle speed | Frequency conversion speed regulation, can achieve two spindle machining at different speeds | ||||||
| Workpiece autobiographical speed | There is no | 100r/min | |||||
| Turntable feed speed | 3s/ per piece | 5s/ per piece | | ||||
| Grinding wheel Specifications | From 650 x 250 x 50 | From 650 x 250 x 50 | From 650 x 250 x 50 | ||||
| Main motor power | 15(KW)×2 | ||||||
| Main engine form factor | 1800(L) x 1200(W) x 2300(H) | ||||||
| Weight of the engine | 5500( kg) | ||||||
| Machining accuracy and beat (mm) | |||||||
| Precision and beat | MKL-650T1 | MKL-650T11 | MKL-650Q | ||||
| Job instance | Overall dimensions | 120(diagonally) x 12(thick) | 55(diameter) x 7(thickness) | 180(diagonally) x 22(thickness) | |||
| | Grinding allowance | 0.15 | 0.08 | 0.15 | |||
| Parallelism | Less than 0.02 | Less than 0.003 | Less than 0.005 | ||||
| Flatness | Less than 0.01 | Less than 0.002 | Less than 0.003 | ||||
| Size control | 0.01 | 0.005 | 0.006 | ||||
| Roughness | 0.8 Ra | 0.4 Ra | 0.4 Ra | ||||
| Loop beat | 3-5 seconds per piece | About 5 seconds for one piece | A piece in 40-50 seconds | ||||
