Commercial Large Capacity Oil Filter Fried Onion Rings Green Peas Peanut Processing Line

Commercial Large Capacity Oil Filter Fried Onion Rings Green Peas Peanut Processing Line

US$2,000.00-5,000.00 1 Piece (MOQ)

Basic Info.

Application Area
Food
Condition
New
Main Material
Stainless Steel
Stirring Type
Spiral
Warranty
One Year
Working
High Speed Mixer
Fuselage Material
304 Stainless Steel
Layout Type
Horizontal
Operating Type
Continuous Operating
Mixer Type
Drum Mixer
Transport Package
Sea Wooden Case
Specification
Support customization
Trademark
Guanhao
Origin
China
HS Code
8479820090

Product Description

Product Parameters
Project Content
Device name Drum cleaning machine
Airframe material 304 stainless steel
Net weight 600(kg)
Packing method Wrap film
Wrap film one year warranty
Product use Drum cleaning
Overall dimension about 3500*1300*1800(mm)
Drum cleaning machine is composed of reducer, pump, drum, bracket, wheel, brush, spray pipe, hopper, cover plate, water tank, valve, transmission shaft, electric frame, electrical control switch and other parts. Through the chain, the motor sprocket drives the long shaft sprocket and then the transition shaft sprocket engages with the stainless steel chain on the drum to make the drum rotate. After the material enters the drum, it is washed through the spray pipe and the board brush to achieve the cleaning effect. There are two water tanks under the drum, close to the water tank of the feed, the water inlet pipe is connected to the water tank, and the circulation water tank is near the discharge side. The water source that washes the material from the punching drum is filtered through the filter in the tank for secondary use.
