New Trend 3cbm Cm3000 Self Loading Concrete Mixer Truck
| US$29,000.00 | 1 Unit (MOQ) |
Basic Info.
Model NO.
CM3000
Type
Concrete Mixer
Shotcrete Type
Wet
Machining Process
Hydraulic
Productivity
180m²/h
Feeding Height
1370mm
Certification
ISO9001: 2000, CE
Condition
New
Color
White
Discharge Way
Automatic
Transport Package
Nude Package
Specification
/
Trademark
CANMAX
Origin
Shanghai, China
Production Capacity
100 Unit/Units Per Month
Product Description
Product Description| CANMAX SELF-LOADING CONCRETE MIXER CM3000 | |
| Integral frame chassis movable, self loading, mixing, transporting | |
| PRODUCTIVITY | BATCH≤15MINS, 4BATCHS/HOUR |
| Driver | 4 x 4 |
| steering | Front steering |
| ENGINE | YUCHAI ENGINE: FOUR-CYLINDER 2200RPM,85KW |
| SPEED | HIGH SPEED: 36.5KM/H; LOW SPEE:6.5KM/H |
| Gear number | Three forwards, three backwards |
| TIRE | 16/70-20 (Steel wire tyre) |
| DRUM | Geometric volume 4.2 cubic meters, the best stirring 2.6-3 cubic meters |
| mixing drum 270°discharges | The tank rotates horizontally to 270 degrees.There is no dead Angle for discharging around the vehicle |
| SHOVEL | shovel capacity: 0.35³ |
| Bucket discharge switch | Hydraulic gate, electric control |
| OPERATION HANDLE | ELECTRIC CONTROL BUTTON FOUR-WAY GUIDE HANDLE |
| WATER SUPPLY | HYDRAULIC DRIVING SELF-PRIMIING PUMPS. |
| Water tank capacity | 370L |
| Diesel tank capacity | 180L |
| whole weight | 6800KG |
