*The XE55DA Excavator is a powerful and versatile machine designed for various excavation tasks. With a robust build and advanced technology, this excavator offers exceptional performance and efficiency on the job site. Equipped with a reliable engine, it delivers high power output while maintaining fuel efficiency, saving you time and money. The XE55DA Excavator features a spacious and comfortable cabin, ensuring operators can work long hours without fatigue. Its precise controls and smooth operation make it easy to maneuver in tight spaces and tackle tough digging conditions. Whether you're working on construction projects, landscaping, or any other excavation tasks, the XE55DA Excavator is the perfect choice for professionals looking for a reliable and durable machine.
*The excavator with short-tail design can apply to the narrow work conditions. The engine powertrain is featured with stable torque output, low fuel consumption and low noise. The load hydraulic sensitive system allows for improved maneuverability of compound actions, faster response speed, accurate control and small impact.
*Strengthen the local area of boom and arm bearing high stress, and meanwhile adjust the structure, disperse stress and improve the service life; standard new-type bucket and reduced bucket depth make unloading quicker and faster.It is easy to achieve fine work such as flat land.
*It is widely used in small earth and stone works, municipal construction, road repair, concrete crushing, buried cables, farmland water conservancy construction, garden cultivation and river channel dredging.

Model	XE55DA
Operating weight(without dozer blade)	5750 kg
Bucket capacity	0.21m³
Engine Rated power/speed	35/2200 kw/rpm
Engine Maximum torque/speed	171.5/1300 N.m
Engine Displacement	2.615 L
Travel speed(H/L)	4.2/2.2 km/h
Rotating speed	10 r/min
Gradeability	≤35°
Ground pressure	31 kPa
Bucket digging force	48.3 kN
Arm digging force	32.5 kN
Maximum tractive force	50.5 kN
Rated flow of main pump	150 L/min
Main safety valve pressure	24.5 Mpa
Travel system pressure	24 Mpa
Swing system pressure	23 Mpa
Pilot system pressure	3.5 Mpa
Fuel tank capacity	110L
Hydraulic tank capacity	85L
Engine oil capacity	9L
Overall length	5860mm
Overall width	1920mm
Overall height	2585mm
Width of platform	1780mm
Track length	1500mm
Counterweight clearance	700mm
Ground clearance	385mm
Max. digging height	5630mm
Max. dumping height	3945mm
Max. digging depth	3830mm
Max. vertical wall digging depth	2680mm
Max. digging reach	6130mm
Min. swing radius	2460mm
