Mic500oz Analyzer for Residual Ozone Concentration Measurement in Denitrification Processes

Product Description

MIC500OZ Analyzer for Residual Ozone Concentration Measurement in Denitrification ProcessesProduct Description
The MIC500-OZ ozone gas analyser has the function of automatically correcting the zero point, in the case of entering the ozone can also automatically correct the zero point of the Ozone Analyzer, in order to ensure the stability of the zero point, is my company has a patent invention of products, the ozone analyzer can be 24 hours continuous operation without downtime.
Detection Principle: UV double light absorption method, used for ozone generator outlet concentration real-time detection or ozone concentration detection of tail gas.
Measurement Range: 0-300g/NM3/0-200g/NM3
Features: patented process, with automatic zero correction, dual-path UV absorption principle, long-life UV LED light source abroad, continuous operation, to ensure the stability of detection concentration.
Product Feature
*Features: Patented technology, with automatic zero correction, dual-path UV absorption principle, foreign long-life UV LED light source, continuous operation, to ensure the stability of detection concentration.
*Test Method: Double light path ultraviolet light absorption method, long life light source system, high measurement accuracy.
*Principle of Measurement: According to Lambert-Peale law, accurate measurement by photo-metric absorption principle.
*Light Source System: Foreign long-life UV light source system (UV LED light source (with Lens)) , free warranty for 2 years.
*Use: Indoor installation, configuration of power and signal terminals.
*Light Cell System: separated light cell technology, no leakage, high pressure, high flow resistance to sampling gas impact.
*Intelligent Compensation: built-in temperature and pressure compensation and display, with light source automatic compensation function.
*Operation Mode: User can select manual zero-setting and automatic zero-setting according to the running state, and can set the automatic zero-setting time.
*Display Unit: g/NM3, MG/NL optional.
*Data Display: High-definition color touch screen, high-concentration range set gas quality flow, real-time output display (optional) .
*Output Function: 4 -20 Ma, RS485 Communication, two sets of alarm point output, electronic flow meter input, etc. .
*Standard Configuration: anti-corrosion flow-meter, ozone tail gas destroyer, intake filter.

Range	Sampling Method	Application Area
0-300g/Nm3	Positive pressure sampling with pressure and temperature compensation	Real-time detection of ozone generator outlet concentration.
0-100g/Nm3	Positive pressure sampling with pressure and temperature compensation	Real-time detection of ozone generator outlet concentration.
0-50g/Nm3	Positive or negative pressure sampling with pressure and temperature compensation	Ozone generator outlet or exhaust ozone concentration detection.
0-1000ppm	Positive or negative pressure sampling with pressure and temperature compensation	Real-time measurement of ozone concentration in the chamber.
0-100ppm	Positive or negative pressure sampling with pressure and temperature compensation	Real-time measurement of ozone concentration in space or room.

Product Parameters

Model	MIC500-OZ
Measuring range	0-300g/Nm3
Optional ranges	0-200g/NM3,0-100G/NM3,0-50G/NM3,0-1000PPM;
Light source life	Approx. 30,000 - 50,000 hours
Sampling method	positive pressure sampling, negative pressure sampling (optional)
Display interface	4.3" touch screen operator interface
Content interface	Ozone concentration, temperature, pressure
Auxiliary functions	Temperature compensation, pressure compensation
Display units	g/Nm3, mg/NL, %WT optional
Display resolution	0.01g/Nm3
Gas flow	0.5L ± 0.2L/min
Input pressure	<0.1 MPa
Concentration error	0.5% FS max
Linearity error	0.5% FS max
Zero point drift	<±0.3%.FS
Response time	0.03 s for signal, 0.3 s for display
Ambient temperature	-20 to 50°C
Piping connection	Quick screw (stainless steel)
Tandem sample aperture	Φ8 (8mm*6mm) (optional)
Bypass sampling aperture	Φ6 (6mm*4mm)
Communication method	RS-485
Output mode	4-20mA (active)
Relay signal	Relay signal for high alarm point, relay signal for low alarm point
Power supply	AC 110-220V
Dimensions	230mm (height) × 330mm (width) × 150mm (depth)
Note	1mg/L = 1g/m3 = 467PPM.
Free warranty	24 months (mainframe sensor)

Installation Instructions
Ozone generator manufacturers, municipal water industry, industrial sewage industry, fine chemical industry, food and drinking water industry, space disinfection industry, pool disinfection industry, flavor synthesis industry and other industries using ozone generator.
