Automatic Roller Shaft Double End Flat Slot Milling Machine for Conveyor Roller Making Machine

Product Description

1.Product use and scope of application:
The product is a special automatic equipment for machining belt conveyor roller shaft with flat groove at both ends. It is suitable for production and processing of roller shaft at home and abroad.This machine uses the domestic advanced superposition valve hydraulic system, realizes the spindle box fast advance, fast back, and can speed speed stepless, the auxiliary man-hour is small, the work efficiency is high, can process the shaft head to pass the flat and the shaft head does not have the groove flat, Two ends of four processing surfaces at the same time.
It takes the imported programmable controller from Taiwan as the core, uses advanced contactless switch as the limit, carries on the program control. The work is stable and reliable, the degree of automation is high, and it is suitable for batch processing of the roller shaft. Is the conveyor industry shaft flat processing necessary equipment.Includes manual, automatic, and customer customization support
2.Technical parameter

project	parameter
model	TX-2023
Spindle rotation number	150r/min
Workpiece center height	850mm
Machining roller shaft diameter	Ф20-Ф40mm
Machining roller shaft length	260-2300mm
Machining shaft groove flat width	6-35mm
milling depth	0-5mm
Spindle motor	3kw×2
Working pressure of hydraulic system	1.5-4Mpa
Machine weight	3000kg
outline dimension	4000×1500×1440mm
