Ndj-8s Liquid Digital Display Viscometer of Laboratory Portable Viscosity Meter

Product Description

Ndj-8s Liquid Digital Display Viscometer of Laboratory Portable Viscosity Meter
Product Description NDJ-D-1S/5S/8S is used to measure the absolute viscosity of Newtonian liquids and the apparent viscosity of non-Newtonian liquids.It can be widely used in oils, paints, plastics, drugs, ornaments, etc. Viscosity measurement of various objects such as paint detergents.
Features *Micro-computer control technology, RS-232C printer interface, correct data acquisition.
*Blue backlight display, high brightness LED display, clear data display.
*The instrument has high sensitivity, good anti-inteference performance.
*The instrument is equipped with four kinds of rotors (No. 1,2,3, 4).
*Has 16 combinations of four rotational speeds.
Product Parameters

Product name	NDJ-Digital Display Viscometer
Model NO.	NDJ-D-1S/5S/8S
Measuring range	5S: 1-1×105mpa.s 8S:1-2×106mpa.s
Rotor specifications	1.2.3.4rotors(0 rotors can measure the viscosity to less than 10mpa.s
Rotor speed	5S: 6.12.30.60 rmp/min 8S: 0.3,0.6,1.5,3,6,12 transfer/score
Single measurement aotumation	When the measurement results are stable, the rotor stops automatically
Measurement accuracy	±2%(Newtonian liquid)
Temperature sensor interface
PC interface
Printer interface
Power supply	AC110-240V 50/60HZ DC12V
Work environment	The relative temperature is not more than 80% when the temperature is between 5 and 35 degrees centigrade
Outline size	380mm*320mm*390mm
Net weight	4.6Kg

Q1:How to order?A: Please send us your purchase order by email or call us sales, or we can make the proforma invoice under your request.We need to know the following information for your order before sending your Pl. Payment methods? T/T, L/C, D/P and so on.
1)Product information-quantity, specification(size, material, technological if needed and packing requirements etc.)
2)Shipping information-company name, street address, phone number,destination sea port. Q2: How to control quality?A,All the raw materials by IQC(Incoming Quality Control) before launch whole process into the process after the screening,
B, Process each ink in the process of IPQC(Input Process Quality Control)patrol inspection.
C, After finished by QC full inspection before packing into the next process packing.
D, OQC before shipment for each slipper to do full inspection.Q3:How do I install and operate the machine myself?A: Our system development is based on the integrated development view, when you get the machine, just connect it to the power supply and the machine is ready to work, as the English software is already installed on the machine, all you need to do is to learn how to use the software, a complete English user manual will be sent to you with the machine.Q4: How do I get technical support after purchase?A: Our factory provides online technical support in English, you can get to know us easily online through Skype, Wechat, WhatsApp or E-mail. If you need any remote assistant support, we will support you through Team viewer software.Q5:What's the warranty for the items?A: We are very confident in our products and we package them very well so you will usually receive your order in perfect condition. The warranty on the equipment is one year (12 months) and if any part of the equipment is damaged within one year due to non-human factors, we will provide a replacement part free of charge.Q6:Can I customize products?A: Yes, OEM&ODM is available! we can provide not only standard machines but also customized machines according to your requirements. Don't hesitate to tell us your requirement, we will try our best to meet your needs.
