Stainless Steel CF8/CF8m Cast Ductile Iron Wafer Type Duplex Butterfly Double Door Disc Dual Plate/Flap/ Swing Check Valve Pn10/Pn16 or 10K/16K Class150 150lb
| US$10.00-100.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
BFHV01-TA01
Material
Cast Iron
Connection Form
Flange
Structure
Butterfly
Pressure
Low Pressure
Function
Ddcv Double Lobe, Nrvr Silence, Sfcv Rubber Lobe, Nrvz Silence, Nrvg Silence
Sealing Form
Rubber Seal
Flow Direction
Unidirection
Standard
DIN
Application
Industrial Usage, Water Industrial Usage, Household Usage
Certificates
Ce ISO Wras Acs
Body Material
Cast Iron/Ductile Iron/Wcb/CF8m/CF8/Al-Bronze
Disc Material
1.4469/1.4529/Saf2205/2507/CF8/CF8m etc
Seat Material
NBR/EPDM/PTFE/Viton/Silicone etc
End Standard
Pn6/10/16/25/21/150lb/JIS5K/10K/As2129 Table D/E/F
Face to Face
En558; ISO5752; ANSI B16.10;API594
Transport Package
Plywood Case
Specification
DN50-DN1200
Trademark
WDS
Origin
Tianjin, China
HS Code
8481804090
Production Capacity
100, 000, 000sets/Year
Packaging & Delivery
Package Size
110.00cm * 110.00cm * 90.00cm
Package Gross Weight
500.000kg
Product Description
Size: | DN50-DN1200 |
| End flange: | ANSI B16.1 125LB BS4504 PN10 & PN16 EN1092-2 PN10 & PN16 AS 2129-2000 Table D Table E ISO 7005 PN10 & PN16 ASME B16.5 150LB JIS B2220 5K/10K |
| Face to face: | EN558-1 Series16, ISO 5752 Series16 , ANSI B16.10 , API 594 125LB,API 594 150LB EN558-1 SERIES 50 |
| Top flange: | ISO 5211 |
| Normal pressure: | PN1.0/1.6MPa(150/200PSI) |
| Body: | CI/DI/WCB/ALB/CF8/CF8M |
| Disc: | DI/ALB/Rubber lined Disc/1.2501/1.4529/CF8/Hastelloy Alloy/Monel |
| Stem: | 410/416/304/431/17-4PH/316/monel |
| Seat: | NBR/Hypalon/EPDM/Neoprene/NR/Wear-Resistant EPDM/Viton/Silicon/Heat-Resistant EPDM/White EPDM/EPDM()/PTFE |
| Suitable temperature: | -10~120 |
| Medium: | Fresh water, sewage, sea water, air, vapor, food, medicine, oils, alkalis, salt etc. |
Product description:
Our check valve is economically priced but with higher quality and capability than most
at this market
Product Feature:
Pressure seal design.
Unique cage unit: entire seat-hinge-pin-disc assembly can be tested outside the valve before seal welding into the body. Eliminates pin seal leakage.
Easy in-line service.
Efficient operation. The hinge pin located near the center of gravity allows the conical seating face of the disc to move out and into the seat rapidly without sliding or wear. The disc pivots through a small arc preventing backflow and "water hammer".
Superior tightness: conical, lapped-in hardfaced seating is self-aligning. Valve can be used even in vertical piping with flow up.
**COMPANY INTRODUCTION
**Company Goal : OEM service for world-famous valve brand.
**Design & Development ability -- SolidWorks, Pro / E, AutoCAD etc
**Dimension Measurement &Inspection
**Assembly Workshop
**Packaging
**Certificates -- CE ISO WRAS ACS certificates
