Multi Heads Trim Saw and Wood Stacker Machine Process Line

Multi Heads Trim Saw and Wood Stacker Machine Process Line

US$180,000.00
1-4 Pieces
US$140,000.00
5-9 Pieces
US$100,000.00
10+ Pieces

Basic Info.

Model NO.
SF8005+8010
After-sales Service
Online
Lead Time
in 90 Working Days
Machinery Test Report
Provided
Applicable Industries
Manufacturing Plant
Condition
New
Transport Package
Plastic Film
Trademark
Saifan
Origin
Shandong, China
Production Capacity
100 Set/Sets Per Year

Product Description

Product Description
SF8005+8010 Automatic Solid Wood Cut-off Sorting And Stacking Machine Line
Advantages:
1,Automatic Solid Wood Cut-off Sorting And Stacking Machine Line
2,Customized base on buyers' request.
3,Flexible adjustment of sawing size.System supports common languages like Chinese, English, Russian, Spanish, French, German.
4,Automatic sensor to detect the finished cutting wood length, choose in control panel where the wood need to go, then automatic sorting head will push it to the place.
5,High quality,perfect after-sales service,engineers design drawings,siemens touch screen and PLC, Schneider electric parts.
6,Design production lines according to customer needs, professional engineers design drawings.
Product Parameters
Automatic cut-off sorting and stacking line can achieve different lengths of wood truncation at the same time, automatic sorting and stacking.
No.
Model
Name
Qty.
1
SF8005
Multi head trim saw
1 set
2

Chain conveyor 5000*4000mm
1 set
3

Waste conveyor
1 set
4

500*22000mm belt conveyor
1 set
5

Sorting head
3 set
6
SF8010
Stacker
1 set
7

900*3200mm chain conveyor
1 set
8

Control cabinet
1 set
9

800*2000mm belt conveyor
1 set

SF8005 Automatic Multi Head Trim Saw Features 5 circular saws, set at either equal or various distances from each other, depending on the application at hand. Each saw head can easily be positioned independently using a lockable saw head positioner. As boards are fed in laterally, these saws cut them individually into shorter pieces all at once.
Model
SF8005
Sawing head quantity
5pc
Feeding length
500-5000mm
First saw blade used for head trimming
Its movable and max. head trimming length 100mm
Distance between first saw blade and last saw blade is max. 5000mm
Min. Distance between saw blade
450mm
Cutting thickness
Max. 120mm (for 1 piece wood)
Max. 60mm (for multi pieces wood)
Feeding block height
60mm
Cutting width
0-300mm
Feeding speed
Max. 6m/min
Frequency control
Out-feeding speed
Max. 60m/min
Frequency control
Cutting accuracy
±1mm
Saw kerf
4mm
Saw blade diameter
450mm*30mm*120T
Sawing head quantity
5pc
Sawing motor
5pc*5.5kw=27.5kw
Total power
27.5kw
Voltage
380v 50Hz 3 phase
Dust collection port
5pc*100mm

SF8010 Automatic Pallet Wood Stacker Machine
Model
SF8010
Pack length
900-1500mm
Pack width
800-1200mm
Pack height
0-1100mm
Raw material length
900-1500mm
Raw material width
50-200mm
Raw material thickness
15-150mm
Productivity
2.5-4min/m3 8-12 layer/min up to raw material width
Power
12kw
Voltage
380v 50hz 3phase
Space
8.7*6.7*2.8m
Weight
3750kg

Detailed Photos
Sorter Conveyors
Automatic sensor to detect the finished cutting wood length, choose in control panel where the wood need to go, then automatic sorting head will push it to the place. Customized conveyors base on your requirements.

Feeders Stacker
Spacer feeders of the SF8010 wood stacker, normally there are 3pcs. Control cabinet of the SF8010 stacker.

Motor Chain conveyor
Powerful motor to control the chain moving, speed is adjustable. Customized chain conveyor with power, can transfer the wood to needed place.

Touch screen Electric parts
Siemens touch screen, with simple view of the machine all sensors positions or status. we use Siemens touch screen and PLC, Schneider electric parts.

Related Products
Related Products Video
SF1000 Wooden Pallet Production Line
SF2000 Wood Pallet Mat Nailing Machine
SF9022 Wood Pallet Legs Nailing Machine
SF9025 Stringer Wood Pallet Making Machine
SF9010 Stringer Wood Pallet Nailing Machine
SF9026 Stringer Wood Pallet Making Machine
SF7013 Double Heads Notcher
SF7030 Wood Pallet Chamfer Machine
SF7041 Pallet Round Corner Cutter Machine
SF6060 Wood Cross Cut Off Saw
SF6021 Wood Double Heads Trim Saw Machine
SF8005 Multi Heads Trim Saw

After Sales Service
1) Seller will send engineer (Chinese speaking, buyer prepare translator) to service in site, all cost in buyer's account (the machine quotation does not include this cost), including all transportation cost between China and buyer factory (two way), visa and insurance cost, hotel and eating responsible by buyer, and extra labor salary.
2) If travel abroad is impossible, then we will send you videos for installation and operation, and supply online guide from
WeChat/WhatsApp, some of our customers work the machines properly through this way. We have English videos for almost every machine, videos about the installation steps, operation steps, maintenance steps, most our customer use the machine succeed base on our videos.
3) Warranty
in 1 year since buyer receive the machine.
In warranty period seller will supply Free parts and online service exclude,
Easy wearing parts (saw blade, cutters, motor belt, small electric components).
Damage by wrong operation.
Out of warranty period seller supply paid parts, Lifelong responsibility.
And our Aftersales service team can supply free online support in 6 days per week, 10+ hours per day.
Below some pictures for your reference.
Company Profile
HICAS group is one leading manufacturing and exporting company of wood working machine in China. We are committed to provide one-stop service to our customers all over the world.HICAS was established in 2003 with two manufacturing centers in Foshan and Qingdao, covering about 40,000 square meter.
1.Founded in 2003.
2.Owns 2 factories manufacturing nailess plywood box machine, wood pallet machine,wood crate machine, nailless plywood box.
3.Owns 70% Market Share(Nailless plywood box machine) in China.
4.Expertized in R&D, Manufacturing, Marketing,Training, and Service.
5.Professional in consultation of Factory construction and Processing Technology, and Technical Improvement Training.
6.Supply Technical Solution base on Cost Analysis and Optimal Allocation.
7.Customer and feedback.
8.Our company and products have been verified onsite by SGS Group
9.Our CE Certifications
10.Our Packaging & Shipping
FAQ
1. Do you offer installation?
Our machines are almost assembled before loading in container. It is very easy for installation in your workshop. Video guidance and English manual can be provided freely. Engineers can be sent to service in site if the buyer request. all cost in buyer's account (the machine quotation does not include this cost), including all transportation cost between China and buyer factory (two way), visa and Insurance cost, hotel and eating in buyer country is responsible by buyer, extra labor salary USD300/day.
2. Where can we get replacement parts?
Most of the spare parts are ready in stock. They will be sent to the buyer directly from our warehouse with original prices.
3. How long can we get replacement parts?
Common spare parts can be delivered by express within one week. Some parts can be purchased locally.
4. What technical support do you offer?
1. Technical support by phone, email or WhatsApp/Skype around the clock.
2. Friendly English version manual and operation video.
3. Engineer available to service machinery overseas.
5. Do you have any machines in our country?
Our machines have been sold to more than 20 countries all over the world, like Russia, Singapore, Uzbekistan, The USA,Malaysia,Peru, Colombia, Vietnam, Slovakia, etc.
6. Can you customized the machine?
Our machines can be customized made according to buyers' request.
7. What other machine do you offer?
We provide one-stop shop service of woodworking machines for the buyers. Other kinds of woodworking machines, like sanding machine, CNC router, drilling machine, saw machine can be provided as well.
8. Can you set the system to our language?
Our system supports common languages like Chinese, English, Russian, Spanish, French, German
