Ck6166 Customized High Precision Quality CE Siemens Fanuc Horizontal Metal Cutting CNC Lathe Machine
| US$15,000.00-45,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
Ck6166
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools
Movement Method
Linear Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.01~0.02(mm)
Performance Classification
Economical CNC Machine Tools
Certification
CE, ISO 9001
Condition
New
Swing Over Bed
530mm,560mm,660mm
Swing Over Cross Slide
310mm,330mm,430mm
Max. Turning Length
750/1000/1500/2000/3000 mm
Spindel Bore
80mm,105mm
Spindel Taper
Mt5
Motor Power
11kw
Transport Package
Plywood Case
Trademark
HOYONG-TRD
Origin
Shandong, China
HS Code
84581100
Production Capacity
30
Product Description
CNC LATHE MACHINE CK6150 ,CK6156 CK6266
Longitudinal and cross feeds are effected by ball leadscrews. Driven by servo motors.
Either vertical or horizontal 4-station or 6-station tool post or gang tools can be selected. The post is located on precision contrite gears with a high repeated positioning accuracy.
Both chuck and tailstock are supplied with hydraulic or manual type.
The spindle system is high in the rigidity and accuracy.
| ITEMS | CK6166/CK6266 | CK6156/CK6256 | CK6150/CK6250 | |
| Max. swing over bed | Ø 660 mm | Ø 560 mm | Ø 530 mm | |
| Max. swing over carriage | Ø 430 mm | Ø 330 mm | Ø 310 mm | |
| Width of bed | 405 mm | |||
| Maximum turned length | 750/1000/1500/2000/3000 mm | |||
| Max. turning length | 650/900/1400/1900/2900mm | |||
| Over gap | Ø 870 mm | Ø 780 mm | Ø 720 mm | |
| Effective length of gap | 230 mm | |||
| Spindle nose | D8 | A2-8 | ||
| Spindle bore | Ø 105 mm | Ø 80 mm | ||
| Cone hole diameter and taper of spindle hole | Ø 113 1: 20 | MT. No. 7 | ||
| Steps of spindle speed(Manual) | 4((Variable Within Each Step) | |||
| Range of spindle speed | 27~135, 55~270, 160~805, 325~1630 r/min | |||
| Rapid feed for Axis Z | 10m/min | |||
| Rapid feed for Axis X | 8 m/min | |||
| Max. travel of Axis Z | 720/970/1270/1970/2970mm | |||
| Max. travel of Axis X | 365 mm | 300 mm | 320 mm | |
| Min. input | 0.001 mm | |||
| Tool post stations | 4-ways or 6-ways | |||
| Tool cross section | 32× 32 mm | |||
| External diameter | Ø 75 mm | |||
| Taper of bore | MT. No. 5 | |||
| Max. Traverse | 150 mm | |||
| X/Z motor torque | 10/10Nm(750~2000)10/22Nm(3000) | 10/10Nm(750~2000) | ||
| Power of main motor | 11 KW | 7.5 KW | ||
| Power of cooling pump | 90W | |||
| Overall dimensions(L× W× H) | 2250/2500/3000/3500× 1250× 1580 mm | 2250/2500/3000/3500/4500× 1200× 1520 mm | ||
| Net weight | 2800/3100/3700/4300/530kg | 2700/3000/3500/4000/460kg | ||
