Mining Equipment Scraper Conveyor Machinery

Product Description

About Us Headquartered in Xinxiang City, Henan Province, China, domestic well-known screening and conveying equipment city, PK Machinery has enjoyed more than 50 steady years of successful growth, and now it has been widely acknowledged as a trustworthy and professional manufacturer in the field of bulk material handling equipment, including vibrating screen, vibrating feeder, belt conveyor, bucket elevator, screw conveyor, scraper chain conveyor and associated spare parts in complete specifications.
Product Description Totally Enclosed Horizontal Scraper En-Masse Chain Conveyor
Horizontal scraper chain conveyor is bulk material conveying equipment, which consists of head section with driving device, connect section, tail section, tension device, as well as scraper and chains.By means of moving chains, it can continuously transport the materials in closed rectangular casing horizontally or at a slight incline.
MS buried scraper conveyor is widely used in cement plant, coal, metallurgy, mining, light, construction, chemical, grain, power industries etc. Product Parameters Technical Parameters

Model	Trough Width	Transport Speed	Material Bulk Density	Capacity	Conveying Length	Installation Angle
	(mm)	(m/s)	(t/m3)	(m3/h)	(m)	(degree)
MS16	160	---0.16 m/s ---0.20 m/s ---0.25 m/s ---0.32 m/s	0.2~1.8 t/m3	15~29	< 80m	0°~30°
MS20	200			23~46
MS25	250			36~72
MS32	320			59~118
MS40	400			83~166
MS50	500			115~230

Working principle
When scraper chain conveyor transports horizontally, the pressure which comes from chains in conveying direction to the materials, and the action which comes from the materials themselves cause internal friction. This friction ensures the stable situation between material layers, and it can overcome external frictional resistance which caused by moving materials in the trough and make materials transport as a whole fluid.
Features

Totally enclosed structure, light weight, small volume;

Convenient installation and maintenance;

Horizontal or slightly inclined transport from 0° to 30°

Multiple material feeding point and discharging point;

Conveying distance is up to 80m with material temperature lower than 120ºC

Widely used in cement plant, coal, metallurgy, mining, light, construction, chemical, grain, power industries etc.

Advantages

Totally enclosed structure, light weight, small volume

Convenient installation and maintenance

Horizontal or slightly inclined transport from 0 to 30

Multiple material feeding point and discharging point

Conveying distance is up to 80m with material temperature lower than 120C

Applications
MS buried scraper conveyor is widely used in cement plant, coal, metallurgy, mining, light, construction, chemical, grain, power industries etc.
Selection condition

Material need to be processed_____?

Feeding size____mm, bulk density____t/m3, material temperature_____degree ?

Processing capacity____t/h ?

Conveying length(distance between inlet and outlet)_____m?

Inclination angle of conveyor______degree?
