3sdm 4sdm Skm Qjd Series Stainless Steel Electric High Pressure Deep Well Submersible Pump with Remote Controller Box for Irrigation
| US$30.00-70.00 | 50 Pieces (MOQ) |
Basic Info.
Model NO.
3SD/4SD
Max.Head
>150m
Max.Capacity
50-100 L/min
Driving Type
Motor
Material
Stainless Steel
Structure
Multistage Pump
Assembly
Liquid Pumps
Power
Electric
Start Up
Electric Pump
Type
Submersible Pump
Application
Submersible Pump
Industry
Agriculture/Home/Garden
Media
Clean Water
Performance
No Leakage Pump
Theory
Electromagnetic Pump
Stator Wire
Copper or Aluminum
Voltage
110V/220V/230V/380V
Frequency
50Hz/60Hz
Pump Diameter
2"/2.5"/3"/3.5"/4"
Impeller
PPO/Stainless Steel
Outlet
Brass/Iron/Stainless Steel
Connector
Brass/Iron/Stainless Steel
Oil Chamber
Brass/Iron
Cable
Black Round or Blue Flat
Outlet Size
1"/1.25"/1.5"/2"
OEM
Available
Speed
2850rpm/3450rpm
Transport Package
Wooden Case/Carton/Pallet
Specification
standard export size
Trademark
Goldpro
Origin
China
HS Code
8413709190
Production Capacity
2000 PCS Each Month
Product Description
Product Description| Applications |
| For water supply from wells or reservoirs. For domestic use, for civil and industrial applications.For garden use and irrigation |
| Operating conditions |
| Maximum fluid temperature up to +35°ºC Maximum sand content: 0.25% Maximum immersion:90m Minimum well diameter: 2.5"/3"/3.5"/4" |
| Motor and Pump |
| Rewindable motor or full obturated screen Single-phase: 110V-127V/60HZ;220V-240V/50Hz Three-phase: 380V-415V/50Hz Equip with start control box or digital auto-control box Pumps are designed by casing stressed NEMA dimension standards Curve tolerance according to lso 9906 |
| Options on request |
| Special mechanical seal Other voltages or frequency 60 Hz Single phase motor with built-in capacitor or control box |
Product Parameters
Packaging & Shipping
1) Packing Details
packed in nylon firstly, then carton, and then reinforced with carton box for outer packing.Or according to client's requirement.
2) Shipping Details
Samples will be shipped within 15 days;
Batch order leading time according to the actual situation.Company Profile
Zhejiang Jinjin Motor Co., Ltd,located in Zeguo Town,Wenling,Taizhou City,China,enjoys convenient land, sea and air transportation network.
We are specialized in all kinds of water pumps.Our main products include Submersible pump of 4SDM series,4SKM series,QGD;QDX submersible pump;Sewage pump of WQD&VSM;Centrifugal pump;Self priming pump.
All our products are produced based on strictly the industry quality standards of world-renowed pumps' companies and we have passed CE certifhcate.Also we have advanced production and processing equipment to ensure quality.
Our products are widely exported to over fifty countries and regions,such as east Europe,Southeast Asia,South America,Middle East,Africa etc.Meanwhile,we have kept well touch with many trading companies at home and abroad for cooperation relationship.
"Reliable quality, Excellent service, Reasonable price, Timely delivery" is our company persistent pursuit.Looking forward to be your long term business partner
Detailed Photos
FAQ
Q:Why choose us?
A:professional water pump supplier for 10 years;
good quality material and advanced test machine
Q:What is your MOQ?
A:100 PCS each model.Af first time,trial order is okay.
Q:What about your warranty?
A:One year,except man-made destroyed.
Q:How about your payment way?
A:30% T/T in advance,70% balance on sight of BL copy by T/T or irrevocable L/C.
Q:Can you make OEM/ODM order?
A:Yes,we are experienced on OEM/ODM order.
