Xh7126 4 Axis Widely Used 3-Axis CNC Milling Machine Fraiseuse CNC Fresadora CNC
Basic Info.
Model NO.
XH7126 4 axis
Application
Metal
Process Usage
Metal-Cutting CNC Machine Tools, CNC Non-Conventional Machine Tools, Metal-Forming CNC Machine Tools
Movement Method
Linear Control
Control Method
Closed-Loop Control
Numerical Control
CNC/MNC
Processing Precision
0.04~0.05(mm)
Performance Classification
High-End CNC Machine Tools
Certification
CE
Condition
New
Transport Package
Packing in Seaworthy Wooden Cases
Specification
Dimension(L*W*H): 2600*1950*2400mm
Trademark
DRC
Origin
China
Production Capacity
500
Product Description
XH7126 4 axis Widely Used 3-Axis CNC Milling Machine fraiseuse cnc fresadora cncAll 3 axis use class precision screw, match up the nut preloading and screw prestretched, preeliminate backlash and temperature rise, so that the machine can achieve stability of the positioning and repeatability accuracy. Besides, the X/Y/Z axis use precision linear rails to ensure the control of the positioning accuracy and processing errors, so that the machine can have high accuracy and long working life.
| Model | XK7132(GSK25i system) | XK7126 (GSK25i system) |
| Travel parameters of 3 axis | | |
| X axis travel | 600mm | 500mm |
| Y axis travel | 400mm | 320mm |
| Z axis travel | 450mm | 450mm |
| X/Y/Z Motor Torque | 8/8/15N.m | 6/6/7.7N.m |
| Spindle nose to table surface | 80-530mm | 90-510mm |
| Spindle center to column surface | 350mm | 360mm |
| Worktable | | |
| Table size | 800×320mm | 800×260mm |
| Max.loading | 400kg | 400kg |
| T Shot | 3×16×110mm | 3×16×110mm |
| Feeding parameters | | |
| X/Y/Z axis rapid feed | 24/24/16 m/min | 24/24/16 m/min |
| Cutting feed | 1-10m/min | 1-10m/min |
| Spindle parameters | | |
| Main shaft connection | Belt | Belt |
| Spindle taper | BT40-120 | BT40-120 |
| Spindle speed | 8000rpm(Optional:10000 ) | 8000rpm(Optional:10000 ) |
| Spindle motor | 3.7KW (Optional:5.5KW ) | 3.7KW (Optional:5.5KW ) |
| ATC paremeters | | |
| ATC capacity | 12qty | 12qty |
| Max.tool dia | Φ92mm(tool from a distance) | Φ92mm(tool from a distance) |
| Max.tool weight | 5kg | 5kg |
| Precision | | |
| Position accuracy | ±0.01mm | ≤0.02mm |
| Repeat positioning accuracy | ±0.003/300mm | ±0.008/300mm |
| Shape and weight | | ±0.005mm |
| Machine size | 2600×1950×2400mm | 2600×1950×2400mm |
| Weight | 2800kg | 2500kg |
