Heavy Duty Big Gap Bed Metal Lathe Machine Cw62103c
Basic Info.
Model NO.
CW62103C
Guide Rail
Horizontal Guide Rail
Tool Holder
Single-tool Holder CNC Lathe
Power Source
Electric
Controlling Mode
Artificial
Automatic Grade
Manual
Setting Mode
Floor-type
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
Modle
Cw62103c
Swing Over Bed
1030mm
Swing in Gap
1200mm
Swing Over Cross Slide
700mm
Distance Between Centres
1500; 2000; 3000; 4500;6000mm
Spindle Bore
105/130mm
Main Motor Power
11kw
Transport Package
W/Case by Sea
Specification
9000KG
Trademark
UNI-TECH
Origin
China
HS Code
8458190000
Production Capacity
200/Momth
Product Description
FEATURE===Heavy Duty Big Gap Bed Metal Lathe Machine CW62103CSPECIFICATION===Heavy Duty Big Gap Bed Metal Lathe Machine CW62103C
| Model | Unit | Model | ||||
| CW62103C | CW62123C | CW62143C | CW62163C | CW62183C | ||
| Swing over bed | mm | 1030 | 1230 | 1430 | 1630 | 1830 |
| Swing in gap | mm | 1200 | 1400 | 1600 | 1800 | 2000 |
| Swing over cross slide | mm | 700 | 900 | 1100 | 1240 | 1440 |
| Distance between centres | mm | 1500; 2000; 3000; 4500;6000 | ||||
| Length in gap from face plate | mm | 380 | ||||
| Spindle nose | C11 or D11 | |||||
| Spindle bore | mm | 105,130 | ||||
| Spindle speeds | rpm/steps | 10-800/18 7-576/18 6-480/18 | ||||
| Cross slide travel | mm | 615 715 815 915 | ||||
| Top rest travel | mm | 225 300 | ||||
| Rapid traverse | mm/min | Axe Z:3200 ,Axe X:1400 | ||||
| Quill dismater | mm | 120 | ||||
| Quill travel | mm | 270 | ||||
| Quill taper | MT6 | |||||
| Bed width | mm | 610 | ||||
| Metric threads | mm/kinds | 1-240/53 | ||||
| Inch threads | tpi/kinds | 30-2/31 | ||||
| Module threads | mm/kinds | 0.25-60/42 | ||||
| Diametral pitch threads | tpi/kinds | 60-0.5/47 | ||||
| Longitudinal feeds | mm/r | 0.07-16.72 | ||||
| Cross feeds | kw | 0.04-9.6 | ||||
| Main motor power | kw | 11 | ||||
| Packing size (mm) | Length | 3840; 4340; 5170; 6670; 8290 | ||||
| Width | 1700 | 1700 | 1850 | 2000 | 2200 | |
| Height | 1980 | 2080 | 2220 | 2280 | 2380 | |
| Gross weight | Kgs | 5900 | 6500 | 7200 | 7800 | 8600 |
| 6250 | 6850 | 7400 | 8200 | 9000 | ||
| 6900 | 7500 | 8100 | 8900 | 9700 | ||
| 8000 | 8600 | 9000 | 9800 | 10600 | ||
| 9000 | 9600 | 10000 | 10500 | 11200 | ||
DETAILS=====Heavy Duty Big Gap Bed Metal Lathe Machine CW62103C
ACCSSORIES====Heavy Duty Big Gap Bed Metal Lathe Machine CW62103C
PACKAGE:
CERTIFICATE:
EXHIBITION:
Our Services:
1. Your inquiry and email will be replied within 24hours.
2. If you need to develop products with your own specification, we can help you to work it out.
3. Always be honest, never lie to customer, and never declare anything we don't have.
4. Customer First:,we offer best Quality and Service!
FAQ:
1. Payment Method:
30% deposit T/T in advance, rest against the copy of B/L or before delivery.
2. Delivery Time:
one week
3. MOQ:
1 set machine.
If you need machine with your own specification, logo, packing, etc, please negotiate with us.
4. Shipping:
For machine: Usually by sea;
For documents: by international express, eg. DHL,TNT or EMS
CONTACT:
TENGZHOU UNI-TECH CO. LTD
Ada
