Focus on DCS, PLC, robot control system and large servo system.
Main products: various modules / cards, controllers, touch screens, servo drivers.
Advantages: supply of imported original products, professional production parts,
Fast delivery, accurate delivery time,
The main brands include ABB Bailey, Ge / fuanc, Foxboro, Invensys Triconex, Bently, A-B Rockwell, Emerson, ovation, Motorola, xyvom, Honeywell, Rexroth, KUKA, Ni, Deif, Yokogawa, Woodward, Ryan, Schneider, Yaskawa, Moog, prosoft and other brands
If the switch itself is not plugged into power, the front panel RPS LED indicator will show that a redundant power supply is now in operation. . This completes the installation. Note: No change in switch configuration is necessary for this installation. 1 Redundant power supply connector 2 AC power connector 1 A4 switch 4 A4 switch redundant power supply connector 2 RPS cable 5 AC power cord (type varies depending on country) 3 STK-RPS-150PS redundant power supply connector 6 AC power outlet with ground connection (type varies depending on country) Note: No change in switch device configuration is necessary for this installation. Connecting to the Console Port for Local Management 2-18 Installation Connecting to the Console Port for Local Management This section describes how to install an RS232 DTE interface cable to a PC, a VT series terminal, or a modem to the A4 for out‐of‐band sessions using CLI commands. What Is Needed The following is a list of interface cables that may be needed to connect the DB9 male Console port connector on the switch. The cables are terminated by a DB9 female connector at one end, and by one of three type connectors at the other end, depending on the type connection needed for the remote device. The cables that may be needed are as follows: • DB9 female‐to‐DB9 female (supplied with switch) • DB9 female‐to‐DB25 female • DB9 female‐to‐DB25 male Using a DTE modem DB9 female‐to‐DB9 female cable, you can connect products equipped with a DB9 DTE male console port to an IBM or compatible PC running a VT series emulation software package. Using a DTE modem DB9 female‐to‐DB25 female cable, you can connect products equipped with a DB9 DTE male console port to a VT series terminal or VT type terminals running emulation programs for the VT series. Using a DTE modem DB9 female‐to‐DB25 male cable, you can connect products equipped with a DB9 DTE male console port to a Hayes compatible modem that supports 9600 baud. The cable used must connect the Console port Received Data, Pin 2 to the Transmitted Data pin at the other end of the cable. The connection from the Console port Transmitted Data, Pin 3 (must be connected) to the Received Data pin cable connection at the other end of the cable. The DB9 Console port pin assignments are shown in Figure 2‐12. Figure 2-12 DB9 Male Console Port Pinout Assignments Note: When switches are connected in a stack configuration and all high-speed stacking cables are connected before powering up the switches, one switch in the stack will be automatically designated as the Manager of the stack and its Console port will remain active. All other switches will become Member switches and their Console ports will be deactivated. 1 Pin 2, Received Data (input) 2 Pin 3, Transmitted Data (output) 3 Pin 5, Signal Ground 4 Pin 7, Request to Send 5 Pin 8, Clear to Send All other pins not connected. Connecting to the Console Port for Local Management Enterasys A4 Fast Ethernet Switch Hardware Installation Guide 2-19 Connecting to a PC To connect a PC, running the VT terminal emulation, to the A4 Console port: 1. Connect the DB9 female connector at one end of the cable (supplied with switch) to the Console port on the A4 switch. (If there is a switch designated as the manager, connect to its Console port.) 2. Plug the DB9 female connector at the other end of cable into the communications port on the PC. 3. Turn on the PC and configure your VT emulation package with the following parameters:
