Best Price Manufacturing Equipment Cat Dog Pet Food Making Machine Pet Food Machine
| US$30,000.00-85,000.00 | 1 Piece (MOQ) |
Basic Info.
Model NO.
HM-95
Screen Mesh
With Screen Mesh
Grinding Equipment Type
Sifter
Pellet Mill Type
Screw Granulator
Bulking Machine Type
Twin Screw Bulking Machine
Expanding Method
Dry Expansion
Condition
New
Applicable Materials Shape
Powder
Warranty
1 Year
Motor Brand
Siemens
Inverter Brand
Delta
Bearings Brand
SKF
Barrel
Alloy
Material of Screw
38CrMoAl
Material of Machine
Stainless Steel
Capacity
600-800kgs/H
Voltage
220V/380V
After Sale Service
One Year Free Service
Material of Products
Fish Meal, Corn Flour, Rice Flour, etc
Certificates
CE/SGS
Transport Package
Wooden Package
Specification
35000*1500*3500mm
Trademark
Himax
Origin
Jinan, China
HS Code
8438800000
Production Capacity
100sets/Year
Product Description
SamplesFull automatic big large capacity pet food production line
1. Production Description Pet food making machine or animal material intended for consumption by dogs or other canines.The pet food is close to the human beings food in the fine level,the heath index and the nutritional ingredients,some of them request more highly than human beings.
2. Technical Parameter
| Model | Installed Power(kw) | Power Consumption(kw) | Capacity(kg/h) | Dimension(m) |
| 65 processing line | 74 | 52 | 120-180 | 17*1.2*2.2 |
| 70 processing line | 95 | 70 | 200-300 | 20*1.5*2.2 |
| 75 processing line | 110 | 82 | 250-400 | 26*1.5*2.2 |
| 85 processing line | 139 | 104 | 400-800 | 28*3.5*4.3 |
| 90 processing line | 132 | 75 | 800-1200 | 28*3.5*4.3 |
| 95 processing line | 165 | 90 | 1500-2000 | 35*3.5*4.3 |
| 120 processing line | 469 | 380 | 2000-2500 | 45*20*22 |
| 135 processing line | 712 | 570 | 3000-3500 | 50*20*25 |
3. Raw materials Fish meal, corn flour, rice flour, soya flour, bone meal, meat, animal oil etc.
4. Different shapes are made by adjusting the dies from extruder 1.0mm,2.0mm,2.5mm,3.0mm,3.5mm,4.0mm,4.5mm...10.0mm depend on fish food dies size
5.Voltage in China
Three phases: 380V/50Hz, Single phase: 220V/50Hz, we can make it according to customers' Local voltage according to different countries. 6. Flow chart
Mixer--- Air conveyor--- Twin-screw extruder ---Hoister --- Dryer ---Flavoring line---Cooler
Our engineer could design the layout drawing according to your dimension of the factory for the fish feed machines.
8. Why choose us
9. Packing and delivery
10. Our Company
