Online Support, Field Installation CE Approved Jwc Sanitary Pads Plant Machine

Online Support, Field Installation CE Approved Jwc Sanitary Pads Plant Machine

US$250,000.00-350,000.00 1 Set (MOQ)

Basic Info.

Model NO.
JWC-KBD450
Real Running speed
350-400PCS/min
Automatic Grade
Automatic
Certification
CE, ISO
Condition
New
After-sales Service
Online Support, Field Installation
Name
Sanitary Napkin Machine
Machine Direction
to Be Defined
Machine Power Source
380V/50Hz
Process
Sanitary Napkin Machine
Usage
98%
Processing Technology
Laminated Machine
Effciency
90%
After-Sales Service Provided
Video Technical Support
Service Provided
Field Maintenance and Repair Service
Transport Package
Transparent Film for Baby Diaper Machine
Specification
180-420mm
Trademark
JWC
Origin
China
HS Code
84418090
Production Capacity
30 Sets

Product Description

JWC-KBD450 Hot Selling Professional Full Frequency Lady Sanitary Pads Napkin Making Machine
Product Description
Sanitary napkin production line includes main machine, glue applicatos, packing system and other accessory equipments include air compressor, vision detection system and metel detection machine etc. Sanitary napkin machine can produce both fluff pulp type and ultra-thin type, with wings and without wings.
We can customize the sanitary napkin with quick-easy package ,individul package and straight package.
This machine will need following materials:fluff pulp,non woven,tissue,film,SAP, glue,ADL,air laid paper, release paper, quick-easy tape
Sanitary napkin machine frame structure and main characters
1. Reasonably solid square steel frame: Panel 20mm thick, adopt specular paint, 6 surfaces processing, solid cage with 60 * 60mm square steel in module design, the base frame with square tube 100mm × 100mm, 18mm thick bottom plate, 6 surface processing also ,widening after gearbox for repair. Spliced type main board by screw, make sure the high efficiency.
2. Crusher system
3. Fluff forming system
4. SAP feeding system
5. Tissue, roll diameter φ800mm (airlaid paper,roll diameter φ1000mm) supply:
6. Fluff core wrapped by tissue
7. Absorbent paper supplyφ1200mm
8. Absorbent paper short cutting device
9. Fluff core inner cut device 1 set, adopt the frame type tool holder structure to improve the service life of the tool roller
10. The waste at both ends of the core body is sucked and collected
11. Top sheet nonwoven(perforated film) supply, roll diameter φ800mm
12. Bottom film supply, roll diameterφ600mm
13. Central release paper device, roll diameter: φ500mm
14. Central release paper cutter
15. Forming cutter
16. Wastage recycling unit
17. Product 180 degree overturn
18. Wing release paper adding unit, φ500mm
19. Wing release paper cutter
20. Product 90 degree turn round
21. Packing film supply, roll diameter φ800mm
22. packaging film and product adhesive roller
23. Second grade warp
24. Product quick easy package exhaust
25. Quick easy tape adding unit
26. Quick easy package sealing
27. Quick easy package cutting unit
28. Reject exist, auto rejecting (air blow)
29. Two way output device
30. Reserve stacker and auto bagger machine
31. Driving system
1. Adopt several servo motors for transmission controlling, main raw materials unwinding driven by frequency control, to guarantee the precision and stability of the machine in high speed, and can realize not change any transmission parts to change the product's size, can directly set on PLC, easy to operate and maintain
2. All cutter racks adopt with CNC processing, guarantee the precision of bade and prolong the cutter's lifetime
3. Cutter adopts servo planetary reducer+ universal joint coupler transmission
4. Stressed timing belt is widen
32. Air supply
1. Vacuum, drum former, dust and wastage collection during production process adopt with several sets air pump and positive pressure blower
2. Air supply is set on the top of machine, made by stainless steel drawing tube, reduce the static electricity, high pressure blower unified air supply, pressure can be adjusted
3. Wastage pipe made by PVC material, each 2 meters has transparent pipe for observing
4. There are two gas supply lines, one is a pressure-holding line for the cylinder and solenoid valve, and the other is a pressure-relief line for the glue gun and waste discharge, without interference.
5. Air tube is set on the top of machine, unified conveyed by galvanized pipe, connect necessary distributing pipe at the nearest place, neatly arrangement
Product Parameters
1 Design speed 450 pcs/min
2 Working speed 350 pcs/min
3
 Qualified rate 98%(calculate based on 7.5 hours, the rate between qualified products and total production quantity, except substandard products caused by glue applicator error)
4 Production efficiency ≥90%( calculate based on 7.5 hours, the rate between real production quantity and theory production quantity)
5 Capacity 150KW (Not including the glue applicators)
7 Power Three phases four wires 380V/50Hz (ground wire)
8 Wire 3×120mm2+1×50mm2+1×25mm2
9 Lowest pressure 6 kg/cm2 ≥0.6mpa
10 Air compressor 2.8 m3/min
11 Total weight About 70 tons
12 Machine size 24*3*4.5 M (L*W*H)
13 Working space 29*4*4.5 M (L*W*H)
14 Machine color Off-white (can be changed by order)
15 Product size One size (according to order)
16 Containers 2×40HQ
17 Packaging: PE cover packing in container
Features at a glance
Auto lubricating System
Auto lubricating for the cutter units ,can make the machine have better cutting effect and extend the life of cutter system		 Human-Machine Interface
Working speed(piece/min), single producing output, monthly output,annual output, counting quantity and products' passing rate can show on the screen		 Materials automatic feeding System
Main raw materials adopt auto unwinding, auto splicing, tension control, auto FIFE web guider functions to guarantee the precise and stablility
Name Brand Origin
1 Servo motor Mitsubishi Japan
2 Auto web guider FIFE USA
3 Touchable screen Banner USA
4 PLC controlling system Mitsubishi Japan
5 Sensor Banner USA
6 Safety production Shneider France
8 Cutter raw material M7 USA
9 Gear according to usage BEM/NSK/SKF Germany/Japan/Sweden
10 Timing belt Optibelt or Gates Germany/USA
11 Low voltage electronic Shneider France
13 Temperature controlling system Omron Japan
15 Pressure regulating valve Airtac Chinese Taiwan
16 Pneumatic element Airtac Chinese Taiwan
17 Solenoid valve Airtac Chinese Taiwan
18 Moisture separator Airtac Chinese Taiwan
19 Automatic fault alarm Mitsubishi Japan
