High Quality Automatic 3-10ton/H Poultry Feed Production Line with Factory Price

Product Description

high quality Automatic 3-10ton/H Poultry Feed Production Line with Factory Price
1.Introduction of our factory:

Our factory Liyang Weifeng Equipmen Co.,Ltd is a professional manufacturer and supplier of feed pellet mill, animal feed pellet mill, poultry feed pellet mill, shrimp feed pellet mill, aqua feed pellet mll, floating fish feeds extruder and complete feed pellet production lines over 20 years.

we can produce and provide pellet mill, complete feed pellet production lines with capacity from 1TPH to 50TPH and floating fish feed line from 1TPH to 10TPH.

During the past years, we have ever set up different capacity complete feed pellet productin lines over the world, such as in Greece,Spain,Algeria,Tunisia,Egypt,Vietnam, Thailand,Bangladesh, India,Malaysia,Indonesia,Korea, Chile, Peru, Brasil, Argentina.....


2.Main Feature of our feed pellet mill,complete feed pellet production line:
1.This feed pellet mill is equipped with screw feeder controlled by FC inverter with permanent magnet to removing iron impurities.
2. Stainless steel conditioner makes even retention and sufficient cooking effect.
3. Gear directly-connecting driving is adopted for high accuracy and efficiency. The output can increase 20% comparing to feed pellet machine driven by belts.
4. High quality bearings(NSK),motor( Siemens or China top brand-Wannan ) is adopted to makes operation smoothly.
5. Main gear and pinion shaft adopt the carbonizing quenching with high accuracy, to ensure smooth driving, low noise and long service life.
6. The ring die& roller assemblies are quickly assembled and disassembled.
7. Applicable for all kinds of high grade animal/livestock/aqua feed. Sinlge, double or three layers of conditioner is optional.
8. Speed-adjust feeding, adopted by this feed pellet machine, can control the feeding capacity correctly to fit for different and meet the production requirement of pellets with different diameters:



3.Technical parameters of feed pellet machine, feed pellet mill:

Model	Main Power	Capacity	Feeder Power	Conditioner Power	Die Diameter	Pellet Size
	(KW)	t/h	(KW)	(KW)	(mm)	(mm)
SZLH350	55	2-5	0.7	3	350	1-18
SZLH400	75/90	3-8	1.1	4	400	1-18
SZLH420	110	5-12	1.1	5.5	420	1-18
SZLH508	132/160	8-15	1.5	7.5	508	1-18
SZLH578	160/185	10-20	1.5	7.5	558	1-18
SZLH678	200/250	15-28	2.2	11	678	1-18

Flow Process for complete feed pellet production line:
Raw material receiving and pre-cleaning →Grinding →Mixing →Pelletizing →Crumbling→Cooling & Sifting →Packing
1. Raw materials receiving and pre-cleaning Process:
Raw materials can be corn, rice bran, soybean, grain, wheat, soybean meal / cake and etc. Precleaner can remove the impurities in raw materials.

2. Grinding Process:
The feed grinder can grind the raw material ingredients to the required size. There are various hammer mills which can satisfy different requirements.
3. Mixing Process:
Mixing is considered to be one of the essential operations in feed pellet processing. Lack of proper mixing may lead to reduced diet uniformity, affecting the feed pellet quality.

4. Pelletizing Process:
Feed pellet mill is the core equipment of the whole production line. According to different raw material, material formula and working condition, we can offer you different pellet mills.

5. Cooling Process:
The feed pellets pressed out by the feed pellet mill are hot and moist. They can't be crushed, screened or packed immediately. Counter-flow feed pellet cooler is designed to cool or dry the feed pellets. It can decrease the temperature and moisture of the feed pellets, preparing for the following processes.

6. Crushing Process:
Different poultry, livestock or aquatic feed pellets are with different sizes. Some big ones should be crushed into small ones. Roll type feed pellet crumbler is just the equipment for feed pellet crushing. Double-roll feed pellet crumbler is suitable for crushing poultry feed, such as chicken feed, duck feed and goose feed etc. Three-roll feed pellet crumbler is suitable to crush aquatic feed including fish feed and shrimp feed etc.
7. Screening, Grading and Packing Process:
The rotary grading sieve can be used to screen and grade the feed pellets. After processing, you can get the qualified feed pellets without fine powder.
Packing Process
The feed pellets should be packed for transporting, storing or selling.
8. Automatic PLC Control System(Customized):
With the automatic PLC control system, the production line is with high efficiency and convenient operation.

Spareparts for feed pellet mill,complete feed pellet production line:
Ring die:
Rollers:
Hammers:

Our services for feed pellet mill,complete feed pellet production line:
(1) Warranty time: 1-3 years, from the date which the product is qualified commissioning. Any damage except the wrong operation during warranty period is repaired freely. But the travel and hotel expenses should be count on buyer.
(2) Commissioning services: the product's installation and commissioning at the demand side, our engineers will not leave there until get your agreement.
(3) Training services: our engineers will train your staff to operate it during the period of installation and commissioning, and they will not leave there until your staff can operate it properly and normally.
(4) Maintenance services: any malfunction happened, once you enquiry us, we will reply you within 48 hours except the special reasons.
(5) Lifelong services: we provide lifelong services for all the products we sold out, and supply the spare parts with discount price.


Contact us:
Welcome to visit our factory, our factory is near Nanjing Lukou Airport and Shanghai Pudong Airport.
Ellen (0086-13951207255)
Liyang Weifeng Equipment Co.,Ltd.
No.108,Jingang Rd,Zhongguancun Science&Technology Park ,
Liyang City, Jiangsu Province,China
Tel: 0086-519-88308600
