Conference Display System 15.6 Inch LCD Lift with Monitor Meeting Screen

Product Description

Functional features:
1. The ultra-thin high-definition display screen is integrated with the elevator design, without exposed connecting wires, connecting backplates, or exposed screws;
2. Paperless ultra-thin 15.6-inch LCD screen lifter, with a resolution of 1920 * 1080P, and a full view LCD screen, the display effect is clear and bright.
3. ★ Circular shaft design, dual bearing support rotation, soft rotation, more comfortable visual effect, non shaking touch, durable and stable.
4. Supports 232 control, remote control, and manual control, compatible with commonly used operating systems, and can be controlled uniformly or in any group, with diverse control methods.
5. The elevator conforms to ergonomic design, and the display screen elevation angle supports 0-30 degree adjustment to meet customers' different elevation needs.
6. ★ The lifting flip screen has an intelligent power outage protection function, and all lines are equipped with standard double insulation and safety grounding anti leakage protection devices, which are non leakage and safe to use.
7. ★ Adopting micro motor, low heat generation, low noise, stable working performance, long service life, the motor can be freely disassembled, and maintenance is simple and convenient.
8. The raised and lowered flip screen desktop panel is equipped with a preset host switch button for more convenient startup, a preset USB information interface, and support for document data import and export.
The LCD screen lifting and flipping device has dustproof and anti-theft functions, and can manually adjust the angle, which is safe and reliable and meets the requirements of different occasions.
10. The internal structure design is reasonable, with a delicate and ultra-thin appearance. The body is exquisite and exquisite, which can better reflect the noble personality, coordinate with the home environment, and have strong decorative properties.
11. Use shielding technology for the display circuit to resist signal and magnetic field interference, without radiation to the human body, and is environmentally safe.The control circuit board adopts a globally advanced integrated intelligent identification chipset, and the limit switch adopts dual protection, with a long service life.
In order to ensure the safety and stability of the product, the manufacturer must have certificates for the power outage and leakage prevention system of the LCD screen lifting and tilting device and the dual limit automatic reset system of the LCD screen lifting and tilting device.
Product parameters:
1. Display screen size: 15.6 inches
2. Display ratio: 16:9
3. Physical resolution: 1920 × one thousand and eighty
4. Display angle: full view
5. Touch screen type: 10 point touch (optional)
6. Interface: 1 × HDMI/VGA, 1 × USB, POWER × 1. Rs232 × one
7. Working environment: Environmental temperature: 5 ºC~40 ºC; Relative humidity: ≥ 75%
8. Working power consumption: AC~220V/50Hz/30W
9. Material color: Aluminum alloy brushed silver/brushed black
10. Installation method: embedded electric lifting installation.
