China Manufacturer′s Direct Sales Dual Axis Solar Tracking Mounting System Solar Tracker
| US$0.013-0.026 | 1,000 W (MOQ) |
Basic Info.
Model NO.
Solar Tracker
Condition
New
Certification
ISO, CE
Application
Home, Industrial, Commercial, Steel Solar Mounting System for Solar Module
Specification
Normal, Aluminum Alloy
Material
Aluminum Alloy
Type
Solar Panel Mounting Accessories
Wind Load
60m/S
Snow Load
1.4kn/M2
Product
Dual Axis Solar Tracking System
Transport Package
Shrinking Film, Carton, Wooden Pallet or by Custom
Trademark
SP
Origin
China
HS Code
76109000
Production Capacity
50000ton/Year
Product Description
/Dual Axis Solar Tracking System/· Higher efficiency, +25%-40% more energy
· No back shadows design for bi-facial solar modules
· Simple structure: Easy for installation and maintenance
· Less power consumption: Only about 3-5kWh/set/year
· High frame strength: Better wind-resistance performance
· Single pole supporting structure: Best terrain adaptability
· Reliable technology, low failure rate, high tracking accuracy
· Smart control, self-positioning & self-correction, low O&M cost
· Rain wash mode: Effectively reduce your solar panels washing times
· Snow prevention mode: Effectively increase your power generation time
· No fixed coverage to sunshine or raining: No affection to plants growing
/Technical Date/
| Item | Parameter |
| Control Mode | Time + GPS |
| Average Tracking Accuracy | 0.1°-2.0°(adjustable) |
| Gear Motor | 24V/1.5A |
| Output Torque | 5000 N.M |
| Tracking Power Consumption(Per Set) | <0.01kwh/day |
| Azimuth Angle Tracking Range | +-50° |
| Elevation Angle Tracking Range | 50° |
| Max. Wind Resistance in Horizontal | >40 m/s |
| Max. Wind Resistance in Operation | >24 m/s |
| Material | Hot-dipped galvanized>65μm |
| System Guarantee | 3 years |
| Working Temperature | -40°C - +75°C |
| Technical Standard & Certificate | CE, TUV |
| Weight(Per Set) | 150-250 KGS |
| Total Power(Per Set) | 1.5kW-5.0kW |
/Main Parts of Dual Axis Solar Tracking System/
| Item | Description | Weight(kg) | Total Weight | Dimension(mm) | Quantity |
| 1 | Vertical Pole | 45.8 | 45.8 | 2000*200*200*2.5 | 1 |
| 2 | L-shaped Bracket | 15.7 | 15.7 | 770*194*5 | 2 |
| 3 | Center Beam | 43.1 | 43.1 | 120*120*4700*2.2 | 1 |
| 4 | Swing Arm | 5.6 | 5.6 | 380*100*50*3.5 | 1 |
| 5 | Swing Arm Fixing Plate | 2.2 | 2.2 | 212*110*120 | 1 |
| 6 | Plastic Bearing | 0.2 | 0.8 | Φ 120 | 4 |
| 7 | Plastic Bearing Limit | 0.25 | 0.5 | 36*50 Angle Steel | 2 |
| 8 | Plastic Shaft Sleeve | 0.1 | 0.2 | Φ 60*45 | 2 |
| 9 | Steel Shaft Sleeve | 0.4 | 0.8 | 70*5 | 2 |
| 10 | Elevation Linear Actuator | 7.0 | 7.0 | 1 | |
| 11 | Azimuth Linear Actuator | 7.5 | 7.5 | 1 | |
| 12 | Azimuth Linear Actuator Fixing Plate | 0.9 | 1.8 | 2 | |
| 13 | Supporting Beam | 8.1 | 40.5 | 55*32*7.5*4578 | 5 |
| 14 | Inclined Strut | 2.2 | 11.0 | 34*16*1.8*2200 | 5 |
| 15 | Control Unit Seat | 0.7 | 0.7 | 1 | |
| 16 | Control Unit | 1.0 | 1.0 | 1 |
