European Standard Upright Z5032C Small Metal Cheap Drilling and Milling Machine
Basic Info.
Model NO.
Z5032C
Structure
Vertical Drilling Machine
Layout
Vertical
Controlling Mode
Artificial
Hole Diameter
<50mm
Automatic Grade
Semiautomatic
Precision
Precision
Certification
GS, CE, RoHS, ISO 9001
Condition
New
ITEM
Z5032C
Max.drilling dia.
32mm
Spindle taper
MT3/R8
Spindle travel
130mm
Spindle speed steps
6
Spindle speed range
50Hz 80-1250rpm 60Hz 95-1500rpm
Distance between spindle nose and table
700mm
Spindle box travel
250mm
Spindle box swivel angle
360/+-90°
Table size
730*210mm
Table travel(X/Y)
500*205mm
Table vertical travel
570mm
Stand table size
417*416mm
Main motor power
0.75kw
Main motor speed
1400rpm
Transport Package
Plywood Case
Specification
1000*950*1850
Trademark
LUZHONG MACHINE TOOL
Origin
China
Production Capacity
7000 Pieces/Year
Packaging & Delivery
Package Size
185.00cm * 75.00cm * 100.00cm
Package Gross Weight
430.000kg
Product Description
Small Metal Cheap Z5032C Vertical Drilling Machine Product DescriptionProduct Parameters
Product main technical Specifications:
| ITEM | Z5032C | Z5040C | Z5045C |
| Max.drilling capacity | 32mm | 40mm | 45mm |
| Spindle taper | M.T.3 or R8 | M.T.4 | M.T.4 |
| Spindle travel | 130mm | 130mm | 130mm |
| Step of spindle speed | 6 | 6 | 6 |
| Range of spindle speed 50Hz | 80-1250 r.p.m | 80-1250 r.p.m | 80-1250 r.p.m |
| 60Hz | 95-1500 r.p.m | 95-1500 r.p.m | 95-1500 r.p.m |
| Min.distance from spindle axis to column | 283mm | 283mm | 283mm |
| Max.distance from spindle nose to worktable | 700mm | 700mm | 700mm |
| Max.distance from spindle nose to stand table | 1125mm | 1125mm | 1125mm |
| Max.travel of headstock | 250mm | 250mm | 250mm |
| Swivel angle of headstock(horizontal /perpendicular) | 360°/±90° | 360°/±90° | 360°/±90° |
| Max.travel of worktable bracket | 600mm | 600mm | 600mm |
| Table size | 730×210mm | 730×210mm | 730×210mm |
| Size of stand worktable of avaliability | 417×416mm | 417×416mm | 417×416mm |
| Forward and afterward travel of worktable | 205mm | 205mm | 205mm |
| Left and right travel of worktable | 500mm | 500mm | 500mm |
| Vertical travel of worktable | 570mm | 570mm | 570mm |
| Motor Power | 1.1kw | 1.1kw | 1.5kw |
| speed of motor | 1400rpm | 1400rpm | 1400rpm |
| Net weight/Gross weight | 430/500kg | 432/502kg | 435/505kg |
| Packing size | 1850x750x1000mm | 1850x750x1000mm | 1850x750x1000mm |
Detailed Photos
Company Profile
FAQ
1:How can I choose the most suitable machines ?
A: Please tell me your specifications ,we can choose the best model for you , or you can choose the exact model .
You can also send us the products drawing ,we will choose the most suitable machines for you .
2: What's your main products of your company?
A: We specialized in all kinds of machines ,such as CNC Lathe Machine ,CNC Milling Machine ,Vertical Machining Center ,Lathe Machines ,Drilling Machine ,Radial Drilling Machine ,Sawing Machine ,Shaper machine and so on .
3: Where is our factory located? How can I visit there?
A : Our factory is located in Tengzhou City ,Shandong Province,277500 China. You are warmly welcomed to visit us.
4. What is your trade terms?
A : FOB, CFR and CIF all acceptable.
5: What's the Payment Terms ?
A : T/T ,30% initial payment when order ,70% balance payment before shipment ;
Irrevocable LC at sight .
5: What's the MOQ?
A: 1 set .(Only some low cost machines will be more than 1 set )
