1000 Liter Floor Cleaner Mixing Machine, Liquid Mixing Machine

Product Description

Jinzong can provide all kinds of chemical products machines as following: > chemical mixing tank > cosmetic mixing tank > Pharmacy mixing tank > Skin Cleaning products making machine
> toilet soap mixing making machine
> face wash vacuum emulsifying machine
> cleansing cream making machine
> cleansing milk making machine
> cleansing lotion making machine
> Soap and detergent manufacturing machines
> Soap and detergent mixing machines
> Laundry cleaning products making machine
> Laundry liquid making machine
> Dishwashing detergents making machine
> Dishwashing Cleaning Liquid mixing making machine
> Household cleaning products making machine
> Floor cleaners detergent making machine
> Glass cleaners detergent making machine
> wood cleaners detergent making machine
> Toilet bowl cleaners detergent making machine
> cosmetics ointment vacuum emulsifiers
> vacuum homogenizer mixer cream emulsion machine
> tomato sauce mayannaise cream vacuum blending tank mixing equipment
> PLC control automatic vacuum cream&ointment emulsifying machine Cosmetic Machine JY/S series Liquid Detergent Mixing Tank is high-efficiency liquid detergent vessel specially designed for mass production. The vessel is equipped with specialized AES self-absorption dissolving decollators, only by opening the valve, plenty of AES materials can be fed within several minutes in the production. AES is dispersed evenly during feeding so it can fully mixed and dissolved in the water, without the frothy phenomenon occurred during normal manual feeding. This equipment can greatly reduce working time and labor intensity, and is suitable for all sorts of cold and hot feeding process.
This series of machines have the mixing blades of many structural shapes for your option, and the vessel body has many shapes such as normal temperature, heating, normal pressure and vacuum, the machine has the advantages of high productivity, low power consumption, strong adaptability and broad usages, it is the ideal equipment to produce liquid detergent products.

Technical Parameter

Specifications	Working volume(L)	the actual volume(L)	Cover power Mpa(for steam)	Figure measure L×W×H(mm)	Mixing power(KW)
100	100	125	≤0.3Mpa	1700× 1200× 1850	2.2
200	200	265	≤0.3Mpa	1800× 1350× 2000	2.2
300	300	400	≤0.3Mpa	2000× 1400× 2100	3
500	500	625	≤0.3Mpa	2200× 1400× 2500	3
1000	1000	1250	≤0.3Mpa	2500× 1700× 2500	4
1500	1500	1750	≤0.3Mpa	2500× 1850× 2500	5.5
2000	2000	2600	≤0.3Mpa	2750× 1910× 3100	5.5
3000	3000	3600	≤0.3Mpa	3000× 2100× 3500	7.5
4000	4000	4800	≤0.3Mpa	3000× 2300× 3600	8.5
5000	5000	5800	≤0.3Mpa	3200× 2400× 3950	11
10000	10000	custom made	≤0.3Mpa	custom made	custom made
20000	20000	custom made	≤0.3Mpa	custom made	custom made
30000	30000	custom made	≤0.3Mpa	custom made	custom made

Note: In case of inconformity of the data in the table due to technical improvement or customization, the real object shall prevail.
