China Manufacturer Full-automatic High Speed Window Patching Machine for Tissue Box Medicine Box and Shirt Box

Product Description

Product Description
PRODUCT OVERVIEWTC-850A Full Automatic High Speed Window Patching MachineSuitable for automatic window filming of window cartons such as tissue boxes, cosmetic boxes, gift boxes, clothing boxes, toy boxes, etc. Corrugated paper is also suitable, and special-shaped cartons are also easy to operate. FEATURES AT A GLANCE1.Hob cutting film + Single group film applicator2.Servo motor paper feeding & film feeding3.Servo motor film feeding4.Paper receiving stepper with batch counting5. Paper vacuum adsorption transport6.Double sheet / empty sheet gluing rising automatically7.Paper length L < 400mm double sheet modePRODUCT SPECIFICATIONSNoItemData1ModelTC-850A2Max paper size580*850mm3Min paper size100*100mm4Paper weightKraft paper: 150-1200g/m24Paper weightWhite Cardboard: 230-1200g/m25Laminating speed Corrugated Paper: ≤3mm5Max Film L320*W350mm6Min Film L50*W20mm7Max Diameter Film Unwinding400mm8Work Speed13000 pcs/h9Quantity of Servo Motor 2 sets (1 set of paper feeding part; 1 set of film feeding part)10Quantity of Stepping Motor2 sets (1 set of automatic paper delivery, 1 set of knife holder left and right)11Machine Size4600*1500*1600mm12Power380/415V 50/60Hz 5.5KW13Weight1680kgPRODUCT CONFIGURATIONPaper feeding sectionOperating interfaceThe paper conveying belt adopts the Japanese Nita brand and durable beef tendon belts, which can be selected according to product needs. If there are many UV products, you can choose Japanese Nita belts to solve the problem of uneven paper conveying. The bottom belt vacuum absorbs the paper and is driven by a servo motor, which can switch multiple paper feeding modes.All the parameters and functions of the switch are operated in the touch screen, and the operation panel is equipped with a "Inch, start, stop, speed adjust" quick operation button.Positioning DepartmentGlue departmentChain guides are made of imported polymer materials, wear-resistant and mute, and paper positioning is made of square pushers to increase the stability of paper in high-speed operation.The special mechanical structure design applies the glue to the product surface quickly and evenly through the sponge gluing method, with good scraping effect.Film sectionDelivery stationThe film feeding adopts servo motor transmission and roller adsorption for continuous pasting. Compared with the traditional intermittent pasting, it has the advantages of fast bonding speed, high precision, and low requirements on the film.The delivery table uses a separate stepping motor to control the belt operation, the stacking distance can be adjusted as a whole or in sections, and it runs at multiple speeds. It can be continuous, paused, and points can be used flexibly.PACKING & DELIVERYCOMPANY PROFILEWhy Choose Us?Strong Manufacturer in post-press equipment for over 12 yearsPrimary strengths of R&D's professional team of 25 engineersComplete solution ready for whole production lineCompetitive prices help develop the market fasterBest-in-class response speed in 24 hoursWhenzhou Feihua Printing Machinery Co., Ltd produces kinds of laminating machine, uv coating machine, folder gluer machine, die cutting & hot stamping machine, paper tube paper box forming machine and BOPP Thermal film, PET metallized film , Soft touch film, etc . With the development and innovation of post-press equipments, our company has carried on deep research and development to post-press equipments combining the features of printing & packing industry home and abroad. The products occupy sizable market at home and also have been expanded to all over the world. Laminating MachineCoating MachineVertical Laminating MachineFolder GluerDie Cutting MachineHot Stamping MachineFlute Laminating MachineRigid Box MachinePaper Tube MachineFAQQ1: What it is advantage of your products?A1: Easily operation and simply maintenance. Also coat effective in market.Q2: How long for the guarantee?A2: 12 month free warranty.Q3: The engineer is available for overseas services?A3: Yes, we supply engineer who is good at communication and understand English.Q4: Why your price is nice than other supplier. (May you was received our machine's quotation but you still can't decided make order now or latter, hope there I not yet miss you.)A4: We are manufacture and our engineer and worker is local. Furthermore. we are more forcus on developing products not advertisement only.Q5: What is the brands for the electrical system?A5: We are using Schneider PLC inverter, Omron and other international brand's parts that ensure the machine could run smoothly.Q6: Which level of your products in market?A6: High and mid grade quality with nice price.Q7: Where are you?A7: We are located in Machine's city Wenzhou, Zhejiang,China, welcome to visit us while you visit China.Q8: Will you supply for OEM or ODM orders?A8: Yes, we are, if you have any advise please let us know that we could make unique machine for you only.CONTACT WITH US
